Intelligent Schneider control system switchgear power distribution equipment GCK Motor Control Center

Beijing Zhongping Technology Co., Ltd 4yr.

Contacts:Huang TingChat

Mobile:86-13811814778

E-mail:ht@gongboshi.com

Click to Contact Yiwugo official customer service for International sourcing.

Yiwugo official customer service X

Whatsapp:

Email： yiwubuy@yiwugo.com

Description
Reviews(/5)

Product descriptions from the supplier

Specification

Item			Parameters
Rated working voltage (Ue) V	The main circuit	AC380V, AC690V
	Auxiliary circuit	AC220V, AC380V; DC110V, DC220V
Rated insulation voltage (Ui) V	The main circuit	AC500V, AC690V
Rated impulse withstand voltage kV (1.2 / 50μs)	Main bus	8kV
	Feeder circuit	6kV
Rated working current A (at IP3X)	Horizontal bus	1000A, 1250A, 1600A, 2000A, 2500A, 3200A, 3600A, 4000A, 5000A, 6300A☀
	Vertical bus	1250A (drawer type), 1500A (drawer type capacity increase type), ≤ 2000A (plug-in MCCB)
Rated short-time withstand current (Icw) kA / 1 second	Horizontal bus	50,80,100
	Vertical bus	50,80,90
Rated peak withstand current (Ipk) kA / 0.1 second	Horizontal bus	105,176,220
	Vertical bus	105,176,198
Protection class	close the door	IP3X, 42, 54
	Open the door	IP2X

Product Description

■ Applicable standards:

GB 7251.1-2013 Low-voltage switchgear and control equipment IEC60439 Low-voltage switchgear and control equipment IEC60529 Enclosure protection level (IP code) Chinese national standard EN61439-1:2011 Low-voltage switchgear and controlgear assemblies - Part 1: General rules EN61439-2:2011 Low-voltage switchgear and controlgear assemblies - Part 2: Power switchgear and controlgear assemblies EN61000-6-2:2005 Electromagnetic compatibility (EMC) - Part 6-2: Generic standards - Immunity for industrial environments EN61000-6-4:2007 Electromagnetic compatibility (EMC) - Part 6-4: Generic standards - Emission standard for industrial environments GB 7251.8-2020 General technical requirements for intelligent complete sets of low-voltage switchgear and control equipment GB / T14048_1 General rule for low-voltage switchgear and control equipment GB / T15576 Low-voltage complete reactive power compensation device GB7947 Color code for insulated and bare conductors JB / T9661 Low-voltage withdrawable complete switchgear

Product features:

Ri4Power is intelligent low-voltage switchgear developed jointly by Shanghai Infraswin Energy Co., Ltd. and Germany Rittal Electro-Mechanical Technology (Shanghai) Co., Ltd. It is modular low-voltage switchgear assembled by factory using standard modules. It is used for the distribution, conversion, control and reactive power compensation of indoor power distribution systems with AC 50Hz or 60Hz, rated operating voltage ≤690V, rated operating current ≤6300A. This product is suitable for applications in power plants, petrochemicals, offshore platforms, metallurgy, paper making, public facilities engineering and other occasions. Ri4Power low-voltage systems provide leading solutions in the field of power distribution and motor control, and provide switch cabinets integrating power and automation for customers in the process industry, power and infrastructure industries, superior safety protection for personnel and equipment, lower operating costs, improve equipment operation availability, reliable, flexible, scalable, and easy maintenance from the front of the switchgear. ■ Use Rittal top-level TS8 cabinet. ■ Protection class IP54, PU foam seal, full of elasticity, resistant to 180 degrees high temperature without hardening. ■ The frame is welded by a unique 16-fold profile, with high strength and excellent load-bearing performance. ■ The surface of the cabinet is treated with oil removal and phosphating, electrophoretic primer, powder sprayed, the surface of the paint has high strength, strong corrosion resistance, grease resistance, weak acid and alkali resistance. ■ An independent metal bus channel is set on the side of the front of the cabinet to keep the communication bus away from power cables and bus bars, reducing interference and easy to install and debug. ■ Adopt special communication connector to connect with intelligent equipment in drawer. ■ Cabinet body adopts modular structure, 25mm modular hole frame, easy to install. ■ Isolation level up to form 4b

It uses the top TS8 cabinet of Rittal

Cabinet surface after oil removal and phosphating treatment, electrophoretic primer, powder spraying, paint surface strength, corrosion resistance, oil resistance, weak acid and weak base resistance.

The front side of the cabinet is provided with an independent metal bus channel, so that the communication bus is far away from the power cable and bus, reducing interference and easy to install and debug.

Use special communication connectors to interface with intelligent devices in the drawer.
