Product descriptions from the supplier
SD card and USB port
2 analog inputs and a broad choice of I/Os
Run/stop switch and cartridge extension
Ethernet and serial line ports
A bus connector is set to distribute data and power supply when coupling Modicon TM3 expansion modules to Modicon PLC
Analogue input typeCurrent 4...20 mA
current 0...20 mA
voltage 0...10 V
Analogue input resolution12 bits
LSB value2.44 mV 0...10 Vvoltage
4.88 µA 0...20 mAcurrent
3.91 µA 4...20 mAcurrent
Conversion time20 ms
Sampling duration10 ms
Absolute accuracy error+/- 0.1 % of full scale at 25 °C
+/- 1 % of full scale
temperature drift+/- 0.02 %FS/°C
Repeat accuracy+/- 0.5 %FS
Non-linearity+/- 0.01 %FS
Cross talk<= 1 LSB
Type of cableTwisted shielded pairs cable
Electrical connection3 x 1.5 mm² 2 screw terminal blocks with pitch 3.81 mm adjustment for inputs
Maximum cable distance between devicesTwisted shielded pairs cable: <30 m for input
InsulationNon-insulated between analogue input and internal logic
Height41 mm
Depth15 mm
Width35 mm
Net weight0.015 kg
Permissible continuous overload13 V, analogue input type: voltage
40 mA, analogue input type: current
Input impedance<= 250 Ohm current
>= 1 MOhm voltage
