Electric current consumption
|
219mA
|
|
Bus Agreement
|
EtherNet/IP
|
|
Address setting
|
Dial switch Settings
|
|
General Cable
|
five twisted pair
|
|
Transmission distance
|
100m(station distance)
|
|
Transmission speed
|
100Mbps
|
|
Output maximum byte
|
024 bytes/ 1024 bytes
|
|
Other Features
|
No
|
|
power input System power input EX SYSTEM POWER INPUT
|
24V(18 〜36V)
|
|
System provides current EX SYSTEM PROVIDES CURRENT
|
2A(Max.)
|
|
power input I/O PORT POWER INPUT
|
24V(±20%)
|
|
I/O PORT CURRENT OUTPUT
|
10A(Max.)
|
|
Expand the number of I/O modules
|
32 pieces
|
|
Type of Control
|
Temperature monitoring, system power monitoring
|
|
Protection grade
|
IP20
|
|
Working Temperature
|
-10~55℃
|
|
Storage Temperature
|
-20~85℃
|
