Item
|
|
|
CJ1W-AD041-V1
|
CJ1W-AD081-V1
|
CJ1W-AD042
|
|
|||||
|
Unit type
|
|
|
CJ-series Special I/O Unit
|
|
|
|
|||||
|
Isolation *1
|
|
|
Between I/O and Controller signals: Photocoupler
|
|
Between I/O and Controller signals:
|
|
|||||
|
|
|
|
(No isolation between I/O signals.)
|
|
Digital isolator (No isolation between I/O signals.)
|
|
|||||
|
External terminals
|
|
|
18-point detachable terminal block (M3 screws)
|
|
|
|
|||||
|
Power consumption
|
|
|
420 mA max. at 5 VDC
|
|
520 mA max. at 5 VDC
|
|
|||||
|
Dimensions (mm)
|
|
|
31 × 90 × 65 mm (W × H × D)
|
|
|
|
|||||
|
Weight
|
|
|
140 g max.
|
|
150 g max.
|
|
|||||
|
General specifications
|
|
|
Conforms to general specifications for CJ Series.
|
|
|
|
|||||
|
Input
|
Number of analog inputs
|
|
4
|
8
|
4
|
|
|||||
|
specifi-
|
Input signal range *2
|
|
1 to 5 V
|
|
1 to 5 V
|
|
|||||
|
cations
|
|
|
0 to 5 V
|
|
0 to 10 V
|
|
|||||
|
|
|
|
0 to 10 V
|
|
- 5 to 5 V
|
|
|||||
|
|
|
|
- 10 to 10 V
|
|
- 10 to 10 V
|
|
|||||
|
|
|
|
4 to 20 mA
|
|
4 to 20 mA
|
|
|||||
|
|
|
|
*3
|
|
*4
|
|
|||||
|
|
Maximum rated input
|
|
Voltage Input: ± 15 V
|
|
|
|
|||||
|
|
(for 1 point) *5
|
|
Current Input: ± 30 mA
|
|
|
|
|||||
|
|
Input impedance
|
|
Voltage Input: 1 MΩ min. Current Input: 250 Ω (rated value)
|
|
|
|
|||||
|
|
Resolution
|
|
4,000/8,000 *6
|
|
1 to 5 V
|
10,000
|
|||||
|
|
|
|
|
|
0 to 10 V
|
20,000
|
|||||
|
|
|
|
|
|
- 5 to 5 V
|
20,000
|
|||||
|
|
|
|
|
|
- 10 to 10 V
|
40,000
|
|||||
|
|
|
|
|
|
4 to 20 mA
|
10,000
|
|||||
|
|
Converted output data
|
|
16-bit binary data
|
|
|
|
|||||
|
|
Accuracy
|
25 °C *8
|
Voltage Input: ± 0.2% of F.S. Current Input: ± 0.4% of F.S.
|
|
|
|
|||||
|
|
*7
|
0 °C to 55 °C
|
Voltage Input: ± 0.4% of F.S. Current Input: ± 0.6% of F.S.
|
|
|
|
|||||
|
|
A/D conversion period *9
|
|
1 ms/250 μs per point *6
|
|
20 μs/1 point, 25 μs/2 points,
|
|
|||||
|
|
|
|
|
|
30 μs/3 points, 35 μs/4 points
|
|
|||||
|
Input
|
Mean value processing
|
|
Stores the last "n" data conversions in the
|
|
Stores the last "n" data conversions in the
|
|
|||||
|
functions
|
|
|
buffer, and stores the mean value of the
|
|
buffer, and stores the mean value of the
|
|
|||||
|
|
|
|
conversion values.
|
|
conversion values.
|
|
|||||
|
|
|
|
Buffer number: n = 2, 4, 8, 16, 32, 64
|
|
Buffer number:
|
|
|||||
|
|
|
|
|
|
n = 2, 4, 8, 16, 32, 64, 128, 256, 512
|
|
|||||
|
|
Peak value holding
|
|
Stores the maximum conversion value while the Peak Value Hold Bit is ON.
|
|
|
|
|||||
|
|
Scaling
|
|
---
|
|
Setting values in any specified unit within a
|
|
|||||
|
|
|
|
|
|
range of ±32,000 as the upper and lower limits
|
|
|||||
|
|
|
|
|
|
allows A/D conversion to be executed and
|
|
|||||
|
|
|
|
|
|
analog signals to be output with these values as
|
|
|||||
|
|
|
|
|
|
full scale.
|
|
|||||
|
|
Input disconnection
|
|
Detects the disconnection and turns ON the Disconnection Detection Flag. *10
|
|
|
|
|||||
|
|
detection
|
|
|
|
|
|
|||||
|
|
Offset/gain adjustment
|
|
Supported
|
|
---
|
|
|||||
|
|
Direct conversion
|
|
---
|
|
A/D conversion is performed and the converted
|
|
|||||
|
|
|
|
|
|
value is refreshed when the ANALOG INPUT
|
|
|||||
|
|
|
|
|
|
DIRECT CONVERSION instruction (AIDC) is
|
|
|||||
|
|
|
|
|
|
executed. This instruction is supported by the
|
|
|||||
|
|
|
|
|
|
CJ2H-CPU[][](-EIP) CPU Units with unit version
|
|
|||||
|
|
|
|
|
|
1.1 or later, and CJ2M-CPU[][].
|
|
|||||
|
|
|
|
|
|
