Best-selling products for foreign trade, available on AliExpress, eBay, Amazon, and Wish.
Charging port output side and input side
Charger output terminal and input terminal
• Microprocessor control (CPU).
• 3 stages of automatic charging:
• Switch mode technology: Yes
• Polarity protection: Yes
• Output short-circuit protection: Yes
•Non-battery connection protection: Yes
• Overvoltage protection: Yes
• Over-temperature protection: Yes
• Cool fan
• Input voltage: 100–240V AC, 50–60Hz
•Rated output: 12V DC, up to 5–6A.
• Minimum operating voltage: 8.0V
• Battery capacity range: 4–100Ah
• Heat protection: 65'C +/- 5'C
• Efficiency: Application. 85%.
•Compliance standards: CB, CE, IEC6035, EN61000, EN55014
• Dimensions (length × width × height): 150×85×60 mm
• Weight: 380 grams
LCD Display: Charging Current
LCD Monitor: Charging Current
LCD Display: Internal Temperature (allowed tolerance)
LCD display: Internal temperature (allowed tolerance)
LCD Display: Battery FULL
LCD monitor: Battery fully charged
Reverse connection protection.
Reverse connection protection.
Short-circuit protection
Output short-circuit protection
The battery connection is correct, and the charger functions properly.
The battery is connected correctly, and the charger functions properly.
Press the “Repair” button to activate battery repair.
Press the "Repair" button to perform pulse repair on the battery.
AC cable length: 60cm, DC cable length: 55cm.
Length of communication cable: 60 centimeters, length of DC cable: 55 centimeters.
Updated color box for packaging
Newly upgraded color box, elegant and beautiful.
Weight with packaging.
