gd350-19-wl series stacker specialized frequency converter gd350-19-wl inviteng specialized frequency converter

1. GD350-19-WL is a high-performance single-drive inverter launched by Invetec based on stacker technology and advanced control theory, integrating specialized functions such as positioning anti-vibration, position control, and brake control.

Mainly used in logistics warehouse stacker, hoist machine, etc.

2. Function Description

Specification indicators

技

"术"在中文中通常指的是技术、方法或技艺。如果是指具体的某个技术或方法，请提供具体的上下文，以便我为您提供更准确的翻译。

"控"在中文中通常指的是控制或掌控的意思。如果是指特定的词汇，请提供上下文，以便我为您提供准确的翻译。

"制"在中文中通常指的是"system"或"measure"。

sex

can

Input Voltage (V)

AC 3PH 380V (-15% to +10%) Rated Voltage: 380V

Output Frequency (Hz)

0 to 150 Hz

Carrier Frequency (Hz)

1.0~15kHz

Control Mode

Space voltage vector control mode, PG-free vector control mode, PG-based vector control mode

Motor Type

Asynchronous motor, permanent magnet synchronous motor

Gear Ratio

1:200 (without PG vector control)

1:1000 (with PG vector control)

Speed Control Accuracy

±0.2% (without PG vector control)

±0.02% (with PG vector control)

Speed Fluctuation

±0.3% (without PG vector control)

±0.02% (with PG vector control)

Torque Response

＜20ms (without PG vector control)

＜10ms (with PG vector control)

Torque Control Accuracy

±10% (without PG vector control)

±5% (with PG vector control)

启动扭矩

0.25Hz/150% (Asynchronous Motor without PG Vector Control)

2.5Hz/150% (Synchronous motor without PG vector control)

0Hz/200% (with PG vector control)

Overload Capacity

150% of the rated current for 1 minute, 180% of the rated current for 10 seconds, and 200% of the rated current for 1 second

Braking Capacity

100% brake power for long-term operation, 120% brake power for 1 minute

运

line

"控"在中文中通常指的是控制或掌控的意思。如果是指特定的词汇，请提供上下文，以便我为您提供准确的翻译。

"制"在中文中通常指的是"system"或"measure"。

sex

can



Frequency Setting Method

Digital setting, analog quantity setting, pulse frequency setting, multi-section speed running setting, simple PLC setting, PID setting, Modbus communication setting, Profinet communication setting, EtherCAT communication setting, etc., to achieve the combination of settings and the switching of setting channels.

Automatic Voltage Adjustment Function

When the grid voltage changes, it can automatically maintain a constant output voltage.

Specialized Function

Double-closed-loop, anti-shake, clutch control, zero servo, master-slave control, load position, application macro, overload protection, torque verification, motor temperature protection, braking protection, and other specialized functions

Protective function

Soft limit, position deviation, ground short circuit, phase-to-phase short circuit, overcurrent, overvoltage, undervoltage, overtemperature, input phase loss, overloading, overheating, output phase loss, communication failure, stall, encoder failure, and more than 30 types of protection functions

outside

surround

connect

"口"在中文中通常指的是人的嘴巴，或者表示开口、开口说话的意思。在英文中，"口"可以翻译为 "mouth"。

Simulated Input

2-way, AI1: 0~10V/0~20mA, AI2: -10~10V

Resolution: Not greater than 20mV

"模拟输出"可以翻译为 "Simulated Output"。

1-way, AO1: 0~10V / 0~20mA

Digital Input

4-way general-purpose input, maximum frequency: 1kHz, DC internal impedance: 10kΩ, AC internal impedance: 40kΩ

High-speed input 2, maximum frequency 50kHz, supports quadrature encoder input, and has speed measurement function.

digital output

High-speed pulse output at 1, maximum frequency 50kHz

1-way Y terminal open-collector output

Relay Output

Two-way Programmable Relay Output

RO1A is normally open, RO1B is normally closed, and RO1C is the common terminal.

RO2A is normally open, RO2B is normally closed, and RO2C is the common terminal.

Contact capacity: 3A/AC250V, 1A/DC30V

Expandable Interface

Three expansion slots: SLOT1, SLOT2, SLOT3 can be expanded with PG cards, communication cards, and I/O cards.

Note: For power ratings of 5.5kW (inclusive) or less, there are only two expansion interfaces, SLOT1 and SLOT2. For power ratings of 7.5kW (inclusive) or more, there are three expansion interfaces.

It

He

Installation Method

Supports three installation methods: wall-mounted, free-standing, and flange-mounted.

Brake Unit

Standard equipped

Operating temperature

-10~50℃，40℃以上降额使用

Protection Grade

IP20

Pollution Level

2级

Cooling Method

Forced Air Cooling
