For traffic signs and safety protection products
| Model Number | Materials | Quantity | Mao Nenjin | Outer box dimensions |
| YS-G13 | ABS+PVC | 50 | 15/11 | 57*31*58 |


1. Features
● Use high-reflective grid lattice sheets (see the image for details).
● Utilize high-brightness LED (see the image for details).
● Utilizes high-performance non-memory batteries; can remain on for over 8 hours during discharge, and blink for over 20 hours during discharge.
● Uses a power-off protection chip; remains functional even when dropped from 3 meters above the ground.
● Use an thickened outer tube of 1.2mm thickness.
● Thickened plastic hooks on the waist belt (tested, no need to worry about breaking).
2. Performance
● Utilizing 6 new-generation environmentally friendly LED lights, which offer high light efficiency and long lifespan, with an average service life of 10,000 hours.
● High-performance non-memory battery with large capacity and long lifespan; it can operate continuously in bright light for over 8 hours after a full charge.
● Enhanced resistance, improved ABS, and optimized structural design; waterproof, dustproof, and power-resistant, suitable for use under various harsh conditions.
● The design is exquisite and attractive, with a compact size and light weight; it can be carried in various ways such as hand holding or waist hanging.
● The color is red; other colors can also be produced if needed.
● Lightweight. With new technologies and processes, the light fixture weighs only 182g, reducing the burden on workers during handling and transportation.
● Long irradiation distance. Advanced optical materials are used for light guidance, resulting in high brightness. It is visible to the naked eye within a range of 1000 meters, and its penetration ability through rain or fog is 300–500 meters.
3. Usage
● Press the light switch to make the lights flash; press it again to switch to constant lighting; press it once more to turn off the lights
● The tail of the light fixture is equipped with a charging port; during charging, simply insert the charger’s output plug into the charging port accordingly.
● The charger features a built-in charging protection mechanism. When the power input of the charger is connected to the lighting device’s charging port, the indicator light turns red, indicating normal charging has begun; once the battery is fully charged, the indicator light changes to green.
● Once fully charged, it can be used at any time within one year; if not used for a long time, it is recommended to recharge for about 6 hours every six months.
● During use, when the battery power is nearing exhaustion, the light brightness will decrease rapidly. In such cases, it should be stopped and charged.
4. Technical Parameters
● Rated voltage DC3.7V
●Rated Capacity 1 800HA
● Light source (LED
● Continuous discharge time ≥8 hours
● Charging Time 6 h
● Battery service life ≥500 (cycles)
