Main information
product line
Acti 9
product name
Acti9 iID
product category
Residual current circuit breaker (rccb
Short name of product
iID
product application
Electrical Vehicle charger
number of poles
4P
Neutral line position
left
Rated current [In]
40 A
Power grid type
AC
Residual current sensitivity
30 mA
Selectivity of residual current action protection
Instantaneous type
Leakage current protection level
Type B-EV (Electric Vehicle)
Quality identification
VDE
NF
IMQ
KEMA
additional information
Distribution system location
Downstream distribution outlet
Incoming line group
Grid frequency
50 Hz
Rated operating voltage [Ue]
400 V AC 50 Hz
Residual current action technology
Action function has nothing to do with power supply voltage.
Rated breaking and connecting energy
Idm 1500 A
Im 1500 A
Rated short-circuit current
10 kA
Rated isolation voltage [Ui]
500 V
Rated impulse withstand voltage [Uimp]
6 kV
On-line operation radiates heat
6 W
Contact position indication
have
Control type
hand shan
Local signal indication
Fault trip indication window
On/off indication
Installation type
Locking clamp locking
Installation mode
DIN guide rail installation
Width (multiple of 9mm)
eight
height
88 mm
width
72 mm
depth
79 mm
net weight
415 g
colour
white
mechanical life
20,000 times
Electrical life
15,000 times
Description of the lock
Padlock device
Wiring ability
Connect 1 ... 1…35 mm² single hard wire in front of double terminal.
Connect 1 ... 25mm cord in front of double terminal.
Connect 1 ... 25mm flexible cord with band hoop in front of double terminal.
1 ... 25mm single stranded hard wire behind double terminal.
1 ... 16mm flexible cord behind double terminal.
1 … 16 mm flexible cord with hoop behind double terminal.
Stripping length
14 mm for upper or lower wiring connection
Tightening torque
3.5 N.m upper wiring or lower wiring
environment
meet a criterion
IEC 61008-2-1
IEC/EN 62423
EN 61008-2-1
product certification
CCC
KC
IP protection level
IP20 conforming to IEC 60529
IP40 (Modular Housing) conforming to IEC 60529
IK protection level
IK05
class of pollution
three
Overvoltage type
IV
Electromagnetic compatibility
Withstand 8/20 s pulse, 3 kA conforms to EN/IEC 61008-1.
Working altitude
0...2000 m
ambient temperature
-25…60 °C
Storage ambient temperature
-40…85 °C
