all new ac/dc wind mobile evaporative energy-saving environmental protection water-cooled air cooler environmentally friendly air conditioner

Trust Lena

Model: 36-DC/AC

Max Air Wind: 4000 m³/h

Voltage：24V

Weight：18KG

Water Tank: 35 L

CBM:0.27m3

The main features of a cold air blower:

① Low investment, high efficiency (about 1/8 of the electricity consumption of traditional central air conditioning)

② Using a cold air fan does not require closing the doors and windows.

③ It can replace the indoor air with turbidity, heat, and unusual odor with fresh air from outside.

④ Low power consumption, each unit uses 1.1 kWh per hour, without using CFCs.

⑤ Each air-cooling machine delivers airflow volume based on the selection: 6000-80000 cubic meters.

⑥ Each unit of cold air coverage is 100--130 square meters.

⑦ Cooling main component (moisture curtain).

Construct:

Cold air conditionerEvaporative CoolerIt is composed of special fiber corrugated honeycomb-like wet curtain with large surface area, high-efficiency energy-saving fans, water circulation system, float ball valve water supplementing device, casing, and electrical components, etc.

Application scope:

Poultry and livestock: chicken farms, pig farms, cattle farms, livestock and poultry breeding, etc.

Greenhouses and Horticulture: Vegetable Storage, Seed Rooms, Floral Planting, Mushroom Cultivation Fields, etc.

Industrial cooling: factory cooling ventilation, industrial humidity, entertainment venues, pre-coolers, air handling units, etc.

Textile, machinery, ceramics, fine chemical, metallurgy, glass, hardware, leather and other manufacturing industries;

Electroplating, electronics, shoe manufacturing, dyeing and printing, plastics, clothing manufacturing, printing, packaging, food processing, and other industries.

Hospital, waiting room, school, waiting room, supermarket, laundry room.

Kitchen, food market, large entertainment center, underground parking garage, and public transportation stations, etc.

Greenhouses, flower farms, poultry and livestock breeding farms.

Existing air conditioning and air supply equipment for modification and installation.

For places with high humidity requirements (such as textile and planting industries), the design can include partial indoor installation.

For places with low humidity requirements, low humidity, and high cleanliness, please consider whether it is suitable for use.

First: Remove the wet curtain (total of four parts, can be removed in any order.)

1. First, tighten the three screws at the top of the wet curtain.

2. Grip the leaves at the top of the wet curtain, gently pull the wet curtain outwards, and then slightly lift it up to remove the wet curtain.

Second: Remove the lid and the water supply assembly.

1. First, unscrew the screws on the lid, and then lift the lid up to remove it.

2. Loosen the clamp on the water supply pipe and release the pipe, then lift the water hose assembly up and remove it.

Third: Cleaning the water pipes.

1. If the holes in the pipe are blocked, you can poke them with a wire to clear them.

2. Clean the dirt on the water pipe with clean water.

The fourth: Cleaning the chassis and accessories.

1. Clean the undercarriage: Use a soft cloth or a brush to clean the undercarriage.

2. Clean the air blades: Use a soft cloth to wipe the air blades. Be careful not to let the dust on the air blades fall into the air duct.

3. Clean the water level sensor: Use a small damp cloth to clean the dirt accumulated on the water level.

4. Clean the water pump: Use a brush to clean the water pump and the dirt accumulated on the filter net.

5. Clean the water drain valve: Pay attention to the dirt at the bottom of the drain valve.

The fifth: Wet curtain cleaning.

1. Rinse the wet curtain from the inside to the outside with clean water (Note: The water pressure cannot be too high when cleaning, and it is strictly prohibited to use acidic or basic cleaning agents to clean the wet curtain.)

2. Filter: The filter can be removed and cleaned once a week. (This applies only to models with a filter.)

Sixth: Cleaning the Filter. The cleaning method is as follows:

1. Unscrew the filter cover.

2. Clean the dirt from the filter: Reinstall the rear cover.

Step 7: After cleaning, reinstall the entire machine in reverse order of the disassembly steps. (Warning: When cleaning the machine set, it is necessary to stop the machine and turn off the power supply to avoid the risk of electric shock or other injuries to the human body.
