[Factory Direct Sales] Dual-Mode 5-Inch 1080P Baby Monitor Monitor Babymonitor Mobile Phone Viewing

本店产装箱明细

外箱尺寸：470x450x387(mm)

一箱数量：20台

重量：17KG

彩盒尺寸：218x184x92（mm)

一套重量：780g

产品型号：BBM6(摇头机，高端款, 支持连接手机远程监控）

产品卖点：

♥ 5寸大屏

♥ 水平旋转355°，垂直旋转120°

♥ 3000毫安大电池

♥ ECO/VOX智能唤醒：延长待机时间

♥ 温度监控（温度差正负2度）；高温/低温警报

♥ 双向对讲（父母端→宝宝端：按住对讲键对讲；宝宝端→父母端：直接传输）

♥ 8首内置固定摇篮曲

♥ 强大稳定的夜视功能

♥ 多角度监控（可水平/垂直方向调节）

♥智能移动/噪音侦测/哭声侦测

♥ 2倍/4倍放大

♥ 喂奶闹钟设置（2小时/4小时/6小时）

♥ 300米无障碍长距离传输，室内传输30米（因环境而异）

♥SD卡，最大支持128G

♥ 父母端可同时连接4个宝宝端摄像头

♥ ECO模式下待机时间可长达22个小时，普通模式下可长达18小时

♥ 支持语言：英语，法语，德语，西班牙语，葡萄牙语，荷兰语，韩语，日语

♥ 电源插头：欧规，英规，美规，澳规, 日规

包装列表

发射端主机X1

接收端主机X1

充电插头(发射端)X1

充电插头(接收端)X1

说明书X1

Baby 5SM+1M

1080P WiFi Indoor PT Camera + 5″ LCD Monitor Screen

Baby 5SM - Camera

Image Sensor

1/2.9'' 2Megapixel CMOS

▶ Dual-band connection

▶ Display on both mobile and monitor screen

▶ Monitor screen of low-power consumption

▶ Transmission distance up to 200m

▶ Two-way audio

▶ Motion/noise/crying detection

▶ Danger zone selection

▶ Feeder reminder

▶ Temperature & humidity detection

▶ Lullaby play

Wireless

IEEE802.11ah

Transmission Distance

Up to 200m

Baby 1M - Audio

Way to Intercom

Two-way audio

Image Resolution

720P (1280 x 720)

Screen Size

5″ LCD

Baby 1M - Network

Dimensions

87 x 74 x 127mm

Net Weight

230g

Baby 1M - Image

Power Supply

DC 5V/1A

Power Consumption

Max. 4.5W

Storage

SD card(Max.128GB), Cloud storage, NVR

Baby 5SM - General

Pan/Tilt

Pan: 0°~350°, tilt: -15°~40°

Operating Temperature

-20 °C to 50 °C

Mobile Phone OS

iOS 9 or later, Android 5 or later

Security

AES128

Max. User Access

6

Communication Protocol

HTTP, DHCP, DNS, TCP/IP, RTSP

Interface Protocol

Private

Wireless

2.4G WIFI (IEEE802.11b/g/n)

Audio Input/Output

Built-in mic/speaker

Alarm Trigger

Intelligent motion/noise/crying detection

Wireless Security

64/128-bit WPA/WPA2, WPA-PSK/WPA2-PSK, WPS

Bit Rate

32Kbps~2Mbps

Frame Rate

1~25fps

Dual Stream

Yes

Lens&FOV(H/V/D)

3.6mm@F2.0, 85°/46°/100°

Baby 5SM - Video&Audio

Compression

H.264

IR Distance

Night visibility up to 10m

Day/Night

Auto(ICR)/Color/B&W

WDR

DWDR

Effective Pixels

1920(H) x 1080(V)

Shutter

1/20~1/10,000s

Min. Illumination

Color 0.1Lux@F2.0,

Black/White 0.01Lux@F2.0

Baby 5SM+1M

1080P WiFi Indoor PT Camera + 5″ LCD Monitor Screen

Baby 5SM - Camera

IWorking Current

330mA

Stand-by Current

12mA

Power Supply

DC 5V/1A

Net Weight

180g

Power Consumption

Max. 2.5W

Baby 1M - General

Operating Temp./Hum.

-20°C~50°C /＜90% without condensation

Storage

SD card (Max. 128GB)

Dimensions

157 x 17 x 81mm

3000mAh rechargeable

Baby 1M - Power

Baby 5SM+1M

1080P婴儿监护云台机 + 5寸LCD监护屏

Baby 5SM-camera

Sensor

1/2.9 ''2 Megapixel CMOS

Dual-frequency connection

dual Screen Display

^

low power consumption screen

^

transmission distance up to 200 meters

two-way intercom

mobile/noise/crying detection

dangerous Area alarm

feeding reminder

temperature and humidity detection

play the Cradle Music

Transmission distance

Up to 200 meters

Baby 1m-voice

Intercom mode

Bidirectional voice

Screen size

5″ LCD

Baby 1m-network connection

Wireless Standard

IEEE 802.11ah

Net Weight

230g

Baby 1m-image

Screen resolution

720P (1280 x 720)

Power consumption

4.5W max

Storage

SD card (up to 128GB), cloud storage, NVR

Size

87 x 74 x 127mm

Pan-Tilt rotation angle

Horizontal: 0 ° ~ 350 °, vertical: -15 ° ~ 40 °

Ambient temperature

-20°C to 50°C

Power supply

DC 5V/1A

Mobile Phone System

iOS 9 or later, Android 5.0 or later

Communication Security

AES128

Baby 5SM-General

Communication Protocol

HTTP, DHCP, DNS, TCP/IP, RTSP

Interface Protocol

Private

Wireless Standard

2.4G WIFI (IEEE802.11b/g/n)

Audio input/output

Built-in microphone

Baby 5SM-network

Alarm trigger

Intelligent Mobile/noise/crying detection

Bit rate

32kbps to 2Mbps

Frame rate

1 to 25fps

Double code stream

Support

Lens & angle of Field of View (horizontal/vertical/diagonal)

3.6mm@F2.0, 85 °/46 °/100 °

Baby 5SM-video and audio

Compression Standard

H.264

Infrared range

The distance can reach 10 meters.

Day/Night switching

Automatic (ICR)/color/black and white

Wdr

Digital WDR

Effective pixel

1920(H) x 1080(V)

Shutter

1/20~1/10,000s

Minimum illuminance

Color 0.1Lux@F2.0,

Black and White 0.01Lux@F2.0

Baby 5SM+1M

1080p baby monitoring PTZ machine +5-inch LCD monitoring screen

Baby 5SM-camera

Power supply

DC 5V/1A

Net Weight

180g

Size

157 x 17 x 81mm

Baby 1m-power battery

Battery

3000mAh rechargeable

330mA

Screen current

12mA

Work current

Storage

SD card (up to 128GB)

Accessories

Power adapter, USB cable

Power consumption

2.5W max

Baby 1m-Universal

Operating temperature and humidity

0~40°C, humidity less than 90% (no condensation)
