Pneumatic pipe joint

1. Definition

Air pipe joint is a pneumatic auxiliary component, which is used to connect and disassemble various components in the pneumatic system conveniently and quickly.1.

2. Specifications and models

3. Straight-through gas pipe joint

• Simple structure, easy installation, commonly used in gas delivery system1.
• Common specifications include 4mm, 6mm, and 8mm.1.

4.T-type gas pipe joint

• Divide one pipe into two, which is often used as branch pipes in gas delivery systems.1.
• Common specifications include 4mm × 4mm × 4mm, 6mm × 6mm × 6mm, etc.1.

5.Y-type gas pipe connector

• Divide one pipe into two, which is often used as branch pipes in gas delivery systems.1.

6. Elbow air pipe joint

• It is used to change the direction of the air pipe and is often used in the turning point of the gas delivery system.1.
• Common specifications include 4mm × 90, 6mm × 45, etc.1.

7. Quick connector

• Gas pipe joints that can be quickly connected and disassembled are commonly used in occasions where frequent air pipes need to be replaced in gas delivery systems.1.

8. Application scenarios

Gas pipe joints are widely used in hydraulic and pneumatic systems of various machinery, especially in application scenarios requiring frequent connection and disassembly.1.

9. Precautions for selection and use

• Select the appropriate gas pipe connector specifications according to the requirements of the gas delivery system1.
• When using, pay attention to the material, pressure resistance and other parameters of the gas pipe joint to ensure the safety and reliability of the system.1
