source manufacturer photovoltaic solar high-power pure sine wave inverter 12 v24v48v72v96 vehicle-mounted home use

Attention:
1. Cannot be used on household electrical outlet
2. Before connecting the battery, please distinguish the positive and negative poles of the battery.
3. Minors are not allowed to use.
4. Note: Waterproof, moisture-proof, shock-resistant, pressure-resistant

When using a 12V/24V cigarette lighter cable in your car, please do not exceed 120W (12V car). 200W (24V truck).

The inverter will automatically protect and disconnect the power supply when the input voltage is lower than 20V or higher than 30V (24V input)
The inverter input is 12V. When the voltage is lower than 10.5V or higher than 15V, it will automatically protect and disconnect the power supply.

Note:

1 battery clip
1 X Battery Bulk Cable
1x Certificate of Qualification
1 User Manual
1 X Pure Sine Wave Inverter
Packing includes:
Outlet: Universal (Common in most socket types worldwide)
Power: 1600W/2200W/3000W
Output Frequency: 50 Hz
Input Voltage: 12V/ 24V/48v/60v/72v Optional
Output Voltage: 220V
Output voltage waveform: pure sine wave
Type: Pure Sine Wave Inverter

1000W inverter, continuous power is 500W, starting power is 1000W.

1600W inverter, continuous power is 800W, starting power is 1600W.

A 2000W inverter has a continuous power of 1000W and a start power of 2000W.

3000W inverter, continuous power is 1500W, starting power is 3000W.

4000W inverter, continuous power is 2000W, starting power is 4000W.

It is 2000W, capable of carrying 1000W or less of ordinary resistive appliances. 3000W can carry 1500W appliances, such as computers, TVs, fans, lights, etc., all of which can be carried with resistive appliances.

However, the start-up power of the sensorial load appliance is 3-12 times, and the continuous power meets the condition. The start-up power must also meet the condition to drive.

For example

If the battery is 12V / 60AH, can I use a 2000W inverter and a 500W hard drill?

1. Firstly, the maximum battery charger is: 12 * 60 * 0.8 = 576W, >500W.

2. Determine whether the appliance is a resistive appliance or an inductive appliance: a hand drill is an inductive drill.

3. The continuous power of the hand drill is 500W, and the continuous time of 2000W is 1000W, and the power is greater than 500W.

The starting power is generally about 3 times (the starting power of the Dofon appliance varies), so 500W x 3 = 1500W, and the starting power of the 2000W inverter is 2000W, > 1500W. Therefore, the 500W hand drill can be used with a 12V / 60AH battery and a 2000W inverter.

Other electrical appliances can also be judged in this way.

If you encounter any problems or are unsure of how to operate, you can also consult customer service. Thank you!

How to Choose the Right Battery for an Inverter

Working hours = U (voltage) × I (battery capacity) × 0.8 × 0.9 ÷ power

Example: 12V 50AH battery with a 220V 100W bulb

Working time = 12V x 50AH x 0.8 x 0.9 ÷ 100W = 4.32 (hours)

Note: 0.8 is the battery discharge coefficient (constant), and 0.9 is the inverter's conversion efficiency (constant).

Model: 5000W Output Waveform: Pure Sine Wave
Rated power: 2500W
Product dimensions: 28*18.5*10.5cm Product net weight: 2.5KG
Note: Measurements are made by hand, with slight errors.
.....................................................................................
Model: 6000W Output Waveform: Pure Sine Wave
Rated power: 3000W
Product dimensions: 30*19*10.5cm Product net weight: 3.2KG
Note: Measurements are made by hand, with slight errors.

.....................................................................................
Model: 8000W Output Waveform: Pure Sine Wave
Rated Power: 4000W
Product dimensions: 34.7*21.2*10.5cm Product net weight: 4.3KG
Note: Measurements are made by hand, with slight errors.

.....................................................................................
Model: 10000W Output Waveform: Pure Sine Wave
Rated Power: 5000W
Product dimensions: 40*21.5*10.5cm Net weight for 24V and 48V products: 5.2KG Net weight for 60V and 72V products: 4.5KG
Note: Measurements are made by hand, with slight errors.

.....................................................................................
Model: 12000W Output Waveform: Pure Sine Wave
Rated Power: 6000W
Product dimensions: 40*21.5*10.5cm Net weight for 24V and 48V products: 5.3KG Net weight for 60V and 72V products: 4.6KG
Note: Measurements are made by hand, with slight errors.
