vertical stainless steel magnetism forle pumps viscous liquid disposable small package shower gel facial cleanser filling machine lcy-1a

Model: LCY-1A
Power: 80W
Dimensions: 15*28*33
Filling Head Count: 1
Filling Capacity: 5-100,000 (ml)
Flow rate: 3000ml/minute
Filling Accuracy: 1%
Applicable objects: disposable small packaging shower gel, facial cleanser, shampoo, juice drinks, carbonated drinks, alcoholic beverages, mineral water, pure water, oils, hair care products, skin care categories, cosmetics, cleaning products, oral liquid, medicine, perfume, essential oil, flower water, fuel additives, gasoline additives, organic solvents.
Applicable industries: catering, food, daily chemicals, medicine, chemistry
Material Type: Liquid

Data program settings Display mode: Upper row shows filling time, middle row shows interval time, lower row shows count display
Dimensions: 320*450*330mm
Weight: 12kg
Filling nozzle diameter: 4mm
Body Material: Stainless Steel
Pump body material: Stainless steel

The characteristics of the Magnetic Pump Liquid Filling Machine:
1. By utilizing microcomputers to control factors such as pumping time, motor speed, etc., the working time and the interval time can be quantitatively and automatically filled to achieve a uniform and repeatable error-small liquid filling method, which is widely applied in industries such as pharmaceuticals, chemicals, food, beverages, oils, cosmetics, etc.

2. The gear pump head of the magnetic pump filling machine is driven by magnetism, and the pump wheel is not connected to the motor by a shaft, so there is no need to worry about leakage due to damage to the shaft seal or the pump overloading and being burned out. Moreover,The pump head is made of stainless steel, resistant to acid and alkali, and corrosion-resistant.It is especially suitable for filling oil, detergents, acid and alkali solutions, and highly corrosive liquids.

3. The machine has a simple structure and is easy to operate. It is controlled by a microcomputer.Can be operated manually, foot switch, or set to automatically fill at a certain time.. Or the feed pipe can be extended.Mobile hose fillingCan meet the filling quantity of more than 5 grams, it is a reliable and durable filling equipment.

4. Often used in small businesses, small shops, and households. Customizable to extend the hose for mobile filling.

Usage Method
Prepare the liquid to be filled, connect the 220V power supply, adjust the filling time and the interval time, set the timer, press the point-and-click switch to test the machine, ensure that the motor is working normally, press the manual key, and control the filling machine with the foot switch, press once to operate the filling machine once, and press the automatic key to let the filling machine work continuously automatically according to the set time.

Steps
1. Time Adjustment for Filling
A. Press the setting key first, and the time will flash. Then press the increase key 0-9 to set the time for that position.
Press the right shift key again to move to the specified position, press the increase key to adjust the time for that position, and repeat the operation to achieve the desired effect.
Press the unit key to move the decimal point up and down to set the time unit.
Press the exit key to complete the setup.
2. Adjustment of Interval Time: The same as the adjustment of filling time. 3. Adjustment of Timer.
Press the setting button, and the timer will blink. Press the increase button 0-9 to adjust the quantity of the corresponding position, and press the right shift button to adjust the quantity of other positions. Set the required quantity.
Press the mode key, when the light is on, the filling machine stops working when the specified quantity is reached. If the light is off, it will continue to work and count continuously. 4. Filling setting Press the filling setting key, the filling machine will start working. When the amount you need is reached, press the filling setting key again. The time displayed on the filling time is the time required to fill the amount.

Model: LCY-1A (This model is a self-priming magnetic pump made of corrosion-resistant stainless steel)

Features:
1. Adjustable time range is large. 0.01-999.9 seconds
2. Corrosion-resistant and high-temperature resistant, the pump body is made of stainless steel, suitable for pumping corrosive liquids.
3. Small Filling Error
4. Quickly set the filling time
5. Easy to clean, when filling different liquids, you only need to remove the filling head to clean, without opening the machine box.
6. With the function of preventing leakage
7. CNC panel display, intuitive
8. The use of microcomputer control makes operation simpler, with the ability to operate using automatic, manual, and foot-operated methods. This is more convenient and more effective.
The size of the discharge nozzle can be replaced according to the size of your bottle opening.
