cy-2d double-headed stainless steel wine filling machine magnetic traditional chinese medicine pump beverage milk chemical tank filling machine

This machine is free for one year warranty, lifetime maintenance, self-produced and sold, after-sales service has more security.

Brand: Zhengdu

Model: CY-2D

Power: 150 (W)

Dimensions: 230*280*450

Filling Head Count: 2

Filling Capacity: 5-100,000 (ml)

Filling Accuracy: 1%

Packing Type: Can

Working Principle: At Normal Pressure

Applicable objects: Juice drinks, carbonated drinks, alcoholic beverages, mineral water, pure water, yogurt, fresh milk, oils, hair care products, skin care category, cosmetics, cleaning, cleaning products, oral liquid, medicine" "Applicable industries: Food and beverage, daily chemicals, medicine, chemical industry

Material Type: Liquid

Name: Dual-Head Stainless Steel Magnetic Pump Microcomputer Liquid Multi-Functional Filling Machine

Features:

1. Adjustable time range is large. 0.01-999.9 seconds

Pump body is made of 316 stainless steel, which can be filled with corrosive liquids and high-temperature liquids.

3, Quickly set the filling time

4, Easy to clean, when filling different liquids, you only need to remove the filling head to clean, without opening the machine box.

5, with leak-proof function

6, the operation is simple, and it can be operated using automatic, manual, and foot-operated control methods.

7, the size of the discharge mouth can be replaced according to the size of your bottle opening.

Model: CY-2D (This model uses self-priming magnetic pumps made of corrosion-resistant stainless steel)

The features of the magnetic pump liquid filling machine: It uses a microcomputer to control factors such as filling time and motor speed of the micro pump to achieve liquid filling equipment, which is widely applied in chemical and daily chemical industries.The pump head is made of 316L stainless steel and is also suitable for filling corrosive liquids and high-temperature environments.Such items as alcoholic beverages, drinks, cooking oil, candles, ghee, glass cleaner, pesticides, etc.Stable and reliable performance, long service life.

This machine has a simple structure and is easy to operate. It can be controlled by a microcomputer, manually, or by foot pedal for filling. It can also move the nozzle and extended hose for filling, making it a reliable and durable filling equipment.It is often used in small businesses, small shops, and families.

Technical parameters:

Flow: 2*5 liters per minute

Working Power Supply: AC220V

Delay Range: 0.01s～999.9s

Counting range: 1 to 59999 times

Work Mode: Power-on Delay Data Program Setting

Display mode: top row shows filling time, middle row shows interval time, bottom row shows count.

Dimensions: 230*280*450mm

Weight: 12kg

Filling Head 2

Diameter: 4mm

Body Material: Stainless Steel

Pump body material: Stainless steel

Instructions: Prepare the liquid to be filled. Connect the 220V power supply, adjust the filling time and the interval time, set the timer. First, press the point-and-click switch to test the machine. If the motor operates normally, press the manual button and use the foot switch to control the filler. Press once to operate the filler once. Press the automatic button, and the filler will automatically and continuously operate according to the set time.

Steps

1. Time Adjustment for Filling

A, press the setting key first, and the time will flash. Then press the increase key 0-9 to set the time for that position.

Press B, then press the right shift key to the specified position, press the increase key to adjust the time for that position, and repeat the operation.

Press the unit key to move the decimal point up and down, and set the time unit

Press the exit key to complete the setup.

2. Adjustment of Intermission Time: The same as the adjustment of filling time.

3. Timer Adjustment

Press the setting button, and the timer will blink. Press the increase button 0-9 to adjust the quantity of the corresponding position, and press the right shift button to adjust the quantity of other positions. Set the required quantity.

Press the pattern key, when the light is on, the filling machine stops working when the specified quantity is reached. If the light is off, it will continue to work and count continuously.

4. Filling Setting Press the filling setting to start the filling machine. When the filling reaches the desired amount, press the filling setting key again. The time displayed on the filling time is the time required to fill the amount.
