Animal/Parcel Platform Scale

Item No: PS

User Manual

This scale has been calibrated prior to shipment, however, accuracy may be affected by variations of gravity, shipment, handling and changes of temperature. Protect the scale from excessive shock, overload, excessive temperature changes & humidity,Use only high quality batteries or an adaptor.

Capacity: 0 –150kg, 200kg, 300kg

Graduation: 0.05kg0.1kg

称量模式:KG, LB, OUNCE.

Operation:

l Insert 4 AA-sized batteries into the scale batteries’ containers (on both sides of the indicator) or connect an adapter.

l Place the scale on a flat, hard, horizontal surface, Press the ON/OFF button to turn on the scale.

l Wait until the LCD shows 0.00 and the scale is ready for weighing.

Errors:

l E" / no display, readjust scale placement or replace batteries.

l "H" weight overload.

Key functions:

l ON/OFF: turn on or turn off.

l MODE: weighing modes in cycle, lb-kg-oz.

l HOLD: 锁定LCD上的重量。

l TARE: zero the weight

l PCS: pieces calculation.

l C/R: There are 2 weighing methods: one is for Animals, when the small triangle shows on the underline, this means it is for animal weighing. When the animal is on the platform, the small triangle continues to flash, this means: it is the exact weight. (At the same time, the LCD words do not flash).

When you press the C/R key again, the LCD will not show the small triangle, this means: for parcel weighing.

SMALL TRIANGLE FOR : ANIMAL, WITHOUT SMALL TRIANGLE: FOR NORMAL PARCEL. (in cycle)

Calibration Instruction:

l Use your left hand finger to press the MODE key and hold it (do not release it)

l Use your right hand finger to press the ON/OFF key, until the LCD shows: E-100

Release both fingers, the LCD will keep on showing E-100, on this stage, when you press the MODE key again, there will be a display showing: E-25, E-50, E-100.(in cycle)

l Place a standard calibration weight, E-25 to mean place a 25 kgs weight, E -50 to mean place a 50 kgs weight, E-100 to mean place a 100 kgs weight for calibration,

The heavier the weight, the more accurate the measurement.

l The LCD will show: "good", and the scale will turn off automatically.

l Remove the weight from the platform and the calibration is over.
