Product specifications details
| Module Type | XHGD-50W |
| Peak Power (Pmax) | 50W |
| MPP Voltage (Vmp) | 1.9V |
| MPP current (Imp) | 2.64A |
| Open-circuit voltage (Voc) | 2.28 V |
| Short-circuit current (Isc) | 2.79A |
| Power Tolerance | ±5% |
| Operating Temperature | -40℃~+85℃ |
| Product certification | CE/ROHS |
| Dimensions | 810*405*2.5mm |
| Number of Cells | 32 PCS (2 * 16) |
| Weight | 0.93 kg |
| Junction Box | IP65 |
| Output Cables | 2.5㎟*900mm |
| Connectors | MC4 compatible |
| Box Size | 9.3 * 4.3 * 4 cm |
| Packing Type | 1 PCS |
| weight | 0.96 |
| QTY/CTN | 5 PCS |
| MEAS | 64 * 22 * 63 |
| G.W: | 7 KG |
1 82 Battery Component Dimensions
Factory production environment and equipment processes
VI Test Instrument
Laminator
Low-power string welding machine
Multi-gate Automatic Spot Welding Machine
Stacked assembly line
EL Test Bench
Automatic slicing machine
