epson 3-4 head uv dtf printer ab film dtf printer hoson i3200u1 i1600u1

caina 2yr.

Contacts:ANN Chat

Mobile:86-19550525187

E-mail:1931817002@qq.com

Click to Contact Yiwugo official customer service for International sourcing.

Yiwugo official customer service X

Whatsapp:

Email： yiwubuy@yiwugo.com

Description

degree of automation: fully automatic

ink type: uv ink

material: crystal sticker

printing plate type: dtf printer

fit print head brand: eps

warranty period: 1 year

brand: caina

origin: zhejiang, china

printing color number and surface number: multicolor

status: new

size (length × width × height): 2300*900 * 700mm

weight: 230

model: nw-uv dtf 420 max

thermal head: 3-4pcs epson i3200u/i160

printing speed: i3200u: 4-way 7 ㎡/h,6-way 5 ㎡/

ink color: cmyk w v/cmyk w v golden clear

all-in-one computer configuration: 8-generation i7-8750h processor, 1920x1

machine configuration: hiwin guiderail, lead

machine function: gold foil application, multi-functional laminating

software: ripprint/phototprint

Epson 3-4 head UV DTF printer A2 clear paint Ab film logo cup packaging 42cm UV DTF printer Hoson I3200U1 I1600U1 head

Model	The maximum value of NW-UV DTF 420	Maximum Printing Size	420 millimeters
printer head	3-4 pieces of Epson I3200U/I1600U
All-in-One Computer Configuration	The eighth-generation i7-8750H processor, 16GB/32GB RAM + 512GB SSD 15.6-inch 1920x1080 touchscreen
Machine Configuration	Hiwin Guiderail, Leadshine Motor, All-in-One (Optional)
Print Speed	I3200U: 4 pass/7 m²/h, 6 pass/5 m²/h I1600U: 8 passages at 4 m²/h, 12 passages at 2.5 m²/h
墨水颜色	CMYK W V/CMYK W V Golden Clear Coat
Software	Ripprint/Phototprint
Work environment	25 ℃-30 ℃ humidity 50%-70%
Packing Size and Weight	："2300900 700 mm, 230 kg

Frequently Asked Questions

Q1: What materials can UV printers print on?

Answer: The printer is a multi-functional printer: Aily uv printer is used on bottles and any material (such as phone cases, leather, wood, plastic, acrylic, pens, golf balls, metals, ceramics, glass, textiles, and fabrics, etc...

Q2: Can LED UV printers print embossing effects?

Answer: Yes, it can print press flower effect. For more information or sample pictures, please contact our representative salesperson.

Q3: Must the product be pre-coated?

Answer: Some materials require pre-coating, such as metals, glass, etc.

Q4: How do we start using the printer?

Answer: We will send the manual and the teaching video using the printer's packaging. Before using the machine, please read the manual and watch the teaching video, and strictly follow the operation structure. We will also provide high-quality service by offering free technical support online.

Q5: What about the warranty?

Answer: Our factory provides one-year warranty: any parts that are used normally (except for print heads, ink pumps, and ink cartridges) will be replaced with new ones within one year (excluding shipping costs). After one year, we only charge for the cost.

Q6: How much does printing cost?
Usually, it costs about $1 per square meter. The printing cost is very low.

Q7: How to adjust the print height?

Answer: Aily UV printer is equipped with infrared sensors to enable the printer to automatically detect the height of the printing object.

Q8: Where can I buy spare parts and ink?

Answer: Our factory also provides spare parts and inks, and you can purchase them directly from our factory or other local suppliers in the market. Customization is also available, and we welcome you to contact us now!
