manual capper portable sewing machine electric seal bag machine woven bag sealing machine

Name: Electric Portable Sealing Machine

Brand: Flying Man Brand

Model: GK9-2

Machine net weight: 3.8 KG

Gross weight: 4.5 kilograms

Internal copper motor, metal gear housing; not an ordinary aluminum motor with plastic gears

Product Uses:
Suitable for factories and warehouses with large production volumes. It can be used for sealing bags of food items such as grain, sugar, and salt, chemical fertilizers, chemical products, metal powders, ores, and other materials.
The single-thread chain stitching produced by this machine features attractive stitching, secure packaging, elasticity, and easy unpacking. It also has a compact structure, simple adjustment, and convenient maintenance. Both screws and nuts are standard parts that are easily available in the domestic market. The machine’s casing is made using an aluminum alloy die-casting process, offering excellent mechanical properties.

1. Scope and performance of cargo aircraft:

Packaging work for canvas bags, burlap sacks, flour bags, woven bags, and paper bags for larger factories and warehouses, suitable for goods such as grain, sugar, salt-based foods, fertilizers, and chemical products.

The single-thread chain stitching performed by this machine features aesthetic appeal, secure packaging, elasticity, and easy unpacking.

2. Introduction to the Packet Airplane Structure

The GK9 type packaging machine features a compact structure, easy adjustment, and convenient maintenance. Both screws and nuts are standard parts that are readily available in the domestic market. The machine's casing is made using an aluminum alloy die-casting process, offering excellent mechanical properties.

3. Major Technical Parameters

Model: GK9-2
Spindle speed: 800 revolutions per minute
Pin spacing: 6-8 MM, adjustable
Sewing thread specifications: 2*3 strands sealed thread
Motor power: 90W
Gross weight, net weight: 4.5KG/3.8KG
