1. Overview DB-BABased on the signals from the building monitoring center, the corresponding windows are executed to open or close, etc., to adjust and control the humidity, temperature, and oxygen content (air volume) in the room, etc., to meet the environmental index requirements of the entire system. This interlocking system reflects the superiority of building intelligence. The system realizes the centralized control of intelligent building shading products and opening window equipment. 2. Functional Features: Power Supply: AC220V ±10%/50Hz Standby Power: DC25V/12AH Static Power Consumption: 12W Environment temperature: -10℃ to +65℃ Relative Humidity: ≤95% (40±2℃) Output Control Capability: One-way interlock output DC24V/25A, current automatic pairing per group Output Control Mode: Fire station signal control priority output control. Manual button (on/stop/off)/Emergency button ◆ Multi-path detection signals, capable of detecting wind, rain, temperature, and intelligent building control ◆ Automatic timing on/off (optional) ◆ Wireless remote control on/off (optional) |
