temperature-resistant touch switch 6*6 touch switch 6*6*5 patch switch button miniature electronic switch

Toggle switchWidely used for:

1. Audio-visual products: MP3, MP4, DVD, sound equipment;

 2. Digital products: digital cameras, digital camcorders, etc.;
 3. Remote control: Remote controls for vehicles, roll-up doors, and home security products.
 4. Communications products: mobile phones, vehicle-mounted telephones, telephones, building equipment, PDAs, etc.
 5. Household appliances: television, microwave oven, rice cooker, electric fan, etc.
 6. Security Products: Video Intercoms, Surveillance Cameras, etc.
 7. Toys: Electronic toys, etc.;
 8. Computer products: cameras, etc.;
 9. Fitness equipment: treadmills, massage chairs, etc.;

Jinchen ElectronicsMass production of various switches, with a comprehensive range of products. Mainly includes:

Toggle switch：

Solder Pad Toggle Switch

Side press switch

Waterproof Toggle Switch

Light Touch Switch with Lights

Touch Switch with Film (Dustproof Touch Switch)

2*3, 3*3 SMD,

2*4 side buttons,

3*6 SMD and side buttonsPlease provide the Chinese text you want to translate, and I will translate it into English for you.

4*4 SMD, 5*5 stickersPlease provide the Chinese text you want to translate, and I will translate it into English for you.

4.5*4.5 SMD and Pin-type"H=3.8-7, choose any one you like,

6*6 SMD and Pin-Headed"H=4.3-25, choose any one you like.

12*12 SMD and Pin-inSquare or round head available, H=4.3-20 optional

Turtle-shaped touch switchMainly used for mobile phone buttons and side buttons.

Turn the switch（mainly miniature toggle switches），

Dial Switch(Also known as a three-way switch, joystick switch, or nodding switch)

Five-way switch(Also known as multi-function switch, mobile phone key switch)

Detection switch(Also known as micro switch)

Push-button switch（也称Locking switch and non-locking switch）

encoding switchEncoder

Ship-shaped switch（KCD1/KCD2/KCD3/KCD4等）

Torch button switch（12*8/12*12/8*8/12*17/13*18/12*18/尾部开关等）

DC socketand2.5/3.5 audio jackAnd so on.

A wide variety of products with various styles available. The product's strength, height, and color can be selected freely. The thickness of the dial switch is also available, with a variety of colors.

The quality of our products is guaranteed, and we offer competitive prices. For larger quantities, we can negotiate the price. We can also develop new products based on customer requirements.

The price of the product may vary due to factors such as height, material, packaging, lifespan, and strength. The specific price is subject to confirmation with the customer service. Thank you!

1. We strive for survival by focusing on quality. Our switch and socket products are of superior quality in the market, and we hope that our clients will not always compare prices blindly. After all, quality is the most crucial aspect.

2、The price of the product varies depending on its height and customer requirements, and the specific price is subject to confirmation with the customer service.

3. Support online banking, transfers, Alipay, and other payment methods.

4. Direct sales by the manufacturer, quality assurance, quality problems can be exchanged or returned within 10 days.

5、Free samples available, shipping cost for orders over 10,000 yuan or 1,000 yuan and above will be borne by us.

6. Jin Chen Electronics offers a wide range of touch switches, toggle switches, and other switch sockets. Please confirm the specific specifications and dimensions with our customer service. If you need a product specification book, please ask our customer service for it. Thank you!

【Jinchen ElectronicsToggle switchSave"]

▲ To prevent the terminal area from discoloring, please do not store the product under the following conditions.

1) High temperature and high humidity environment

2) in an environment with corrosive gases

3) direct sunlight areas

【Jinchen ElectronicsToggle switchUse"]

1. Operating Method

▲ Do not apply strong force repeatedly. If you press the handle button further under the condition that it has already been pressed, excessive load weight may cause the spring (tumbler) to deform, which could become the cause of poor performance.

▲ Especially if excessive load is applied to the transverse compression type, the rivet joint may become damaged, causing the switch to break. Therefore, when installing or operating, please note not to apply a load weight exceeding the excessive load weight (29.4N, 1 minute, 1 time).

Press the handle to set the direction switch for vertical movement. Pressing only one side of the handle or operating obliquely may result in reduced durability.

2、Dust Control Measures

Because the switch has no sealed construction, please do not use it in places with dust. If you have to use it, you should consider adopting protective measures such as covering it.

Jinchen ElectronicsToggle switch的正确使用方法【关于印刷基板】【关于焊接】" The correct usage of "【关于印刷基板】【关于焊接】" The correct usage of "【关于印刷基板】【关于焊接】

1. About the Printed Circuit Board

●Printing boards should be used with a standard of single-sided boards with a thickness of t=1.6mm.
● Using different thickness substrates and substrates with double-sided perforations may affect the clearance of the switch, the insertion of the substrate, and the heat resistance of the solder joints. These factors can vary depending on the perforation and substrate design. Therefore, it is recommended to conduct confirmation tests to achieve the desired results.
● When performing the board splitting operation after installing the switches on the printed board, there may be scattered board powder entering the switch interior. Please take this into full consideration. Especially when due to the surrounding environment or workbench, or when the container and the board are overlapped, it is very likely that the board splitting powder or foreign matter will adhere to the switches, which may cause poor contact.

Section Two: About Welding

1. General Precautions for Welding
● Multilayer laminate boards, etc. should be confirmed in advance through testing. Heat generation and deformation may occur depending on the type of substrate, the design of the substrate, and the different grounding methods.
● Including manual correction welding in the re-welding, the number of welding operations should be less than or equal to 2. In this case, there should be a gap of less than 5 minutes between the first and second operations. Wait until it returns to normal temperature before proceeding. If it is continuously heated, it will cause deformation of the external contours and damage to the performance.

2. Applications for automatic wave soldering troughs (B3F, B3W, B3WN, B3J)
● Welding temperature: below 260°C
● Welding Time: Less than 5 seconds (Single-sided Substrate t=1.6mm)
Preheating temperature: below 100°C (ambient temperature)
Preheating time: within 60 seconds
● Please note that do not let the foam solder contact the printed circuit board on the switch installation side, if there is foam solder on the board, it may enter the switch and cause poor conductivity.

3. Reflow Oven (Surface Mount)
Please weld within the temperature curve range indicated in the diagram at the terminal section.

● According to the reflow soldering equipment, there may be cases of higher peak values. Please ensure that a confirmation test is conducted.

● If surface-mount switches are soldered in a reflow welding trough, the welding gas and flux are easily introduced, which can lead to a malfunction of the switch operation. Therefore, it should be avoided.

4、Hand-welded applications (for all series)

Welding temperature: Iron tip temperature below 350°C
Welding Time: Less than 3 seconds (Single-sided Substrate t=1.6mm)
Please confirm that the switch has not popped up from the base board in front of the welding personnel.

Qin Chen Electronics Co., Ltd. in Yueqing is a professional enterprise that integrates the research and development, manufacturing, sales, and service of electronic products. The company mainly operates a variety of touch switches, detection switches, button switches, waterproof switches, lighted switches, toggle switches, five-way switches, wheel switches, earphone sockets, boat-type switches, DC sockets, self-locking switches, flashlight switches, and micro-switching elements. The products are widely used in fields such as computer peripherals, household appliances, testing equipment, audio-visual equipment, communication equipment, and automobiles.
