Description

protection level: ip68

type: multi-nozzle flowmeter

origin: kaifeng, china

connectivity: flange type

custom service: oem, odm, obm

flow rate: 0.001

measuring range: 999999

warranty: 2 years

product name: waterman water meter

certificate: iso9001

temperature grade: t30 type

pressure level: map 10

upstream fluency sensitivity level: u0 level

low flow sensitivity level: d0 level

maximum allowable error q1-q2: ± 5%

maximum allowable error q2-q4: ± 2%

installation: horizontal installation

keywords: water meter

Supplier's product description

Product Description

Specifications

model	Nominal size	L millimeters	High millimeters	W millimeters	Thread connection				W 8 kilograms
model	Nominal size	L millimeters	High millimeters	W millimeters	model				W 8 kilograms	Outer side of flange: Φ mm	Thread maintains a central circle of Φ mm	Thread connection number
LXLC-50E	50	200	232	380	165	125	4 * M16	12
LXLC-65E	65	200	232	380	185	145	4 * M16	13
LXLC-80E	80	225	252	360	200	160	8 * M16	16
LXLC-100E	100	250	262	380	220	180	8 * M16	18
LXLC-125E	125	250	2.75	380	250	210	8 * M16	20
LXLC-150E	150	300	325	420	285	240	8 * M20	38
LXLC-200E	200	350	352	420	340	295	8 * M20	64
LXLC-250E	250	450	470	660	395	350	1 2 * M20	9.4
LXLC-300E	300	500	492	660	445	400	1 2 * M20	114
LXLC-400E	400	600	631	750	555	515	16 * M20	199
LXLC-500E	500	80	740	840	670	620	20 * M20	340

Note<t_1234567890> <t_987654321

1. Temperature Class: T30

2. Pressure Level: MAP10

3. Pressure loss level: △ P40

4. High-end traffic sensitivity category: U0

5.Downstream traffic sensitivity level: D0

6. Low-region (Q1)≤Q≤Q2) Maximum permitted error:± 5%

7.High Region (Q2)≤Q≤Q4) Maximum permitted error: ± 2%

8. Flange connections shall comply with the dimensions specifications for PN10 integral cast iron flanges in GB/T71241.6-2008 and 2.0.
Special specifications of the order. Dimensions and weight; all major technical parameters shall be in accordance with product and order requirements.
