| black | CN¥ 0.0 |
*The default camera signal for shipping this product is AHD; the camera connector is BMW type (please leave a message if other signals or connectors are required)
Technical Parameters:
| Project | Option A | Option B | Option C | Plan D |
| Image sensor | AHD-720P | AHD-960P | AHD-1080P | CVBS |
| Optical lens | 1/3 | 1/3 | 1/3 | 1/3 |
| Effective pixels | 1,280 * 720 | 1,280 * 960 | 1920 * 1080 | 960*592 |
| TV Format | NTSC/PAL | NTSC/PAL | NTSC/PAL | NTSC/PAL |
| Output video format | AHD | AHD | AHD | CVBS |
| Signal-to-noise ratio | >46db | >46db | >52 dB | >45 dB |
| Electronic Exposure Method | Automatic | Automatic | Auto Exposure | Auto Exposure |
| Gain Control | Automatic Gain Control | Automatic Gain Control | Automatic Gain Control | Automatic Gain Control |
| Color Control | Automatic | Automatic | Automatic | Automatic |
| Minimum illuminance | 0.001 LUX / F1.2 | 0.001 LUX / F1.2 | 0.001 LUX / F1.2 | 0.01LUX / F1.2 |
| Horizontal Field of View of the Lens | 150 degrees | 150 degrees | 150 degrees | 150 degrees |
| Vertical Field of View of the Lens | 150 degrees | 150 degrees | 150 degrees | 150 degrees |
| Gamma value | 0.45 | 0.45 | 0.45 | 0.45 |
| Working Voltage | 12V–35V | 12V–35V | 12V–35V | 12V–35V |
| Response time (from power on to the first frame of output image) | 2S | 2S | 2S | 0.5 seconds |
| Power consumption | 0.6W | 0.6W | 0.7w | 0.5w |
| Operating Humidity | <90% | <90% | <90% | <90% |
| Operating Temperature | -40℃ to 80℃ | -40℃ to 80℃ | -40℃ to 80℃ | -40℃ to 80℃ |
| Waterproof Rating | IP6.8 | IP6.8 | IP6.8 | IP6.8 |
Company Profile:
Since its establishment in 2010, Shenzhen Jinkechuang Technology Co., Ltd. has always adhered to technology as the guide and quality as the core principle.
First, the customer-first business philosophy. Over the years, the company has focused on the research, development, and production of vehicle security systems.
Developed in-vehicle cameras, in-vehicle displays, in-vehicle radars, dashcams, in-vehicle Bluetooth headphones, and security systemsSeries of products. Combining technological innovation and excellent management principles, while achieving product diversity. ProductionThe products cover countries and regions such as the United States, South Korea, and Japan. Shenzhen Jinkechuang Technology Co., Ltd. welcomes trade.Companies, 4S stores, pre-installation and post-installation services, auto parts agents, etc. visit our factory with the goal of achieving win-win and multi-win outcomes in business operations.
We are committed to providing you with the highest quality service!
Customer Instructions:
1. If any technical issues arise, please contact us during working hours as much as possible, so that we can provide detailed assistance immediately.
Reply.
2. Please conduct the inspection promptly after receiving the goods. If there are no issues, please confirm the payment within three working days.
3. If non-human-induced quality issues occur within one year, the company promises to provide free repair services for customers.
4. The company does not accept returns or exchanges due to issues other than product quality.
5. The company provides lifetime maintenance for all products sold.
6. If you are satisfied, please give a 5-star rating; your feedback is a great support and encouragement for us.
Note: The shipping fee for this product is calculated based on the quantity ordered and the shipping location. For details, please contact customer service!
