hot sale high quality liquid filled pressure gauge en837 standard

Contacts Allen Chat

Mobile 86-15267973249

15068986842

Click to Contact Yiwugo official customer service for International sourcing.

Yiwugo official customer service X

Whatsapp:

measuring range: optional composite material, pressure range from 0 to 6000 ps

pressure gauge type: pressure indicator, analog pressure gauge, barometer, m

model: 115bl

origin: anhui, china

custom service: oem

material: stainless steel/brass

product name: liquid filling pressure gauge

free sample: available

window opening: polycarbonate or glass

case: stainless steel

liquid: glycerin or silica gel

socket and pipe: brass or 316 stainless steel

pressure range: -30 "mercury-0-15000psi

accuracy: 1.6% or 1.0%

certificate: iso, ce

Highly Sold High-Quality Liquid Pressure Gauge EN8X37 Standard

Product Description

Product Name:	Highly Sold High-Quality Liquid Pressure Gauge EN8X37 Standard
Normal size	1.5" (40mm), 2.0" (50mm), 2.5" (63mm) 3" (75 millimeters), 4" (100 millimeters), 6" (150 millimeters).
Pressure Range:	-1 Bar (-3 0"Hg) – 0–1000 Bar (1500 Psi)
Accuracy:	±1%, ±1.6%
Operating Temperature:	-20°C to +60°C
Case:	304 Stainless Steel
Table Ring:	304 Stainless Steel
Patton Tube:	Copper alloy or stainless steel <100Bar: Type C ≥100Bar: Spiral type
Connection Method:	Brass or 316 stainless steel
Sports:	Brass or 316 stainless steel
Dial:	Aluminum
Indicators:	Aluminum
Window Opening:	Polycarbonate or glass
Threading:	1/8", 1/4", 3/8", 1/2"; PT(BSPT,ZG), BSP(G,PF), NPT, etc.
Liquid:	Glycerin or silicone oil
Gasket, Fill Cap	Nitrile orSilicone
