Description

gps positioning accuracy: 10

battery service life: 720

type: automotive gps locator

antenna type: ceramic antenna

map function: electronic fence alarm, track playback function, multi-source switching

material: silicone, pc,abs,tpu

item no.: tk202tk600tk905

origin: shenzhen

model: tk202

TK202 Packaging Dimensions

Single host size/weight: 74mm x 43mm * 31mm, 145 grams

Single set: 1.17 * 8.8 * 5.5 cm / 0.145 KG

50-piece box: 44*33*28 CM / 1.2 kg

Model: TK905

Single host size/weight: 90mm x 72mm * 22mm, 166.8 grams

Package size and weight per set: 13*11*6 cm/0.293 kg

50-unit box: 53*28*32 CM / 16.5 KG

Model: TK915

Package size and weight per set: 13*11*6 cm/0.4 25 kg

50-unit box: 53*28*32 CM / 22 KG

TK918

Package size and weight for a single set: 13*11*6 cm/0.6 kg

50 pieces, 5.2*3.2*2.8 cm, 30 KG

TK900 4G + 2G

1 box: 1.7*8.8*5.5 cm / 0.286 KG; 50 boxes: 3.5*2.7*2.4 cm / 1.5 KG

undefined

undefined

done

Real photo of the SMT production workshop. Please do not copy the image; violators will be held accountable!

undefined

生产车间

Product detail images are shown:

undefined

Product Advantages

1. Magnet + waterproof bag, can be attached to a vehicle for real-time positioning

2. Multiple positioning options: free search, globally applicable, available via computer and app

3. Smart Power Saving Mode

4. Small volume dimensions: 4.6*6.4*1.7 mm (1.8*2.5*0.6.5 inches), weight 40 grams, integrated design (built-in antenna and battery), no installation required, easy to carry.

5. Supports multiple positioning methods: can query real-time latitude/longitude, time, and speed; automatically returns positioning information when the phone call ends.

6. If the device enters an underground parking lot or other GPS blind spot, it will report the location information of the device’s latest positioning to you.

7. Add/Remove Authorization Number Function.

8, Electronic Fence

9. Shift Alarm:

10. Speed limit warning:

11, Low battery alert function.

12. New vibration alert added

3. For single positioning, simply tap an app when you want to locate, or keep the device in standby mode to save power when you don’t need to locate.

14. Insert the mobile SIM card, place the device outdoors, and it will automatically connect to the network. No settings are required; it is simple and easy to use, and no installation is needed.

15. You can view the three-month historical trajectory.

Technical Parameters

1, GPS chip: UBLOX chip

2. Number of channels: 20 parallel channels

3. Sensitivity: -1.59 dBm

4, Accuracy: 5 meters

5. Positioning time: Cold boot/heat boot time: 35/1 seconds

6, Optional Car Charger

4 specifications

Content	Specifications
Size	3.1 mm x 4.3 mm x 7.4 mm
weight	143g
Internet	GSM/GPRS
Network frequency bands	850/900/1800/1900 MHz
Chip	UBLOX chip
GPS Sensitivity	-1.59 dBm
GPS accuracy	5 meters
First startup time	Cold status 45 seconds Warm status 3 minutes and 50 seconds Hot status 1s
Car charger voltage	1 2—2 4V input 5V output
Handheld charger voltage	110–220V input 5V output
Battery	Chargeable, interchangeable 3.7V Li-ion battery tk2_0_2A:6_4_0_0A_H tk202B:4400AH
Standby duration	2.4 hours
Storage Temperature	-40°C to +85°C
Working Temperature	-20°C to +55°C
humidity	5%–95% non-condensing

5. Precautions

1. GPS signals are only available outdoors; use GPS for positioning.

2. Verify the mobile card has call, SMS, and GPRS internet access functions.

3. Confirm that there is sufficient balance.

4. Verify that call display is enabled and turn off call forwarding.

5. For the first use, charge for at least 4 hours.

6. Insert the GSM phone card correctly.

7. Do not disassemble or assemble the equipment.

8. Please use the USB cable and charger provided by the manufacturer.

9. Time sleep is a single positioning mode, while vibration sleep and off sleep are continuous positioning modes.

Command list

NAME	Command	For example	reply
Initialization	start+password	begin1 2 3 4 5 6	start well
Set the GMT time zone number	time zone + password + space + local time zone	time zone1 2 3 4 5 6 8	Time zone is OK
Set authorized number	admin+password+space+phone umber	admin1_234_56 phone umber	admin ok
Cancel authorized number	noadmin+password+space+phone umber	noadmin123456 phone umber	noadmin OK
SOS alarm	Long-press the SOS button after entering the authorization number.
route record (<t_XXXXXX> needs a TF card)	gpx+password t001m***n+password	Gpx123456 t001m***n123456	GPX is okay tn ok
Battery inspection	check+password	check123456
IMEI verification	IMEI+password	IMEI123456	IMEI number
Switch to SMS mode	SMS + password	SMS123456	SMS OK
Switch to the GPRS mode	GPRS+password	gprs123456	GPRS OK
change password	password+old pass+space+new pass	password1 2 3 4 5 6 8 8 8 8 8	password ok
Restore Default Settings	reset+password	reset123456	Reset OK

Update time：20260808161714

tk202b/5000 ma	CN¥ 118.0
tk202a/6600 ma	CN¥ 132.0
tk600 (1500 ma)	CN¥ 78.0
4g universal tk202b	CN¥ 148.0
4g universal tk202a	CN¥ 162.0
tk900 4g 10000 ma	CN¥ 175.0
tk905/5000 ma	CN¥ 200.0
tk905b	CN¥ 230.0
tk915/10000 ma	CN¥ 220.0
4g version tk905	CN¥ 230.0
4g version tk915	CN¥ 245.0
4g tk905b	CN¥ 270.0
tk918	CN¥ 292.0
tk302a (6000mah)	CN¥ 230.0
tk302b(10000mah)	CN¥ 255.0
4g version tk905 + battery charger	CN¥ 245.0

locator gps tracking locator container elderly positioning children locator
