Technical Parameters
■ Rated voltage: AC100V~240V ±10%, 50–60Hz
■ Power: 550W
■ Light bulb: Original Taiwan-made YODN 380w
■ Color temperature: 7500K
■ Bulb life: 1500 hours
■ Control Modes: Self-propelled, Master-Slave, DMX, Voice Control
■ DMX Channels: Dual-channel operation mode, 17/21 international DMX channels available for switching
■ Signal input: Standard three-pin/five-pin signal socket input and output
Function Introduction
■ Display: Equipped with a 1.8-inch LCD display, operated via an external rotary control, showing both Chinese and English text
The interface features built-in gravity sensing, which automatically flips for inverted display when installed upside down.
■ Pattern disc: 1 fixed pattern disc, 1 with 4 fixed patterns + white light; each pattern has shaking effects
Motion effect, pattern disk with forward/backward, fast/slow, flowing effect
■ Color disc: 1 color disc, 1/4 color + white light; each color segment can be paired with adjacent colors
The film features a semi-color effect, with both directions allowing slow and fast flow.
■ Rainbow Disc: Features a built-in seven-color disc that creates a dazzling rainbow effect.
■ Double Prism:
15+25+35 honeycomb prism combination + 8 prisms; the unique dual-prism design allows them to interact with each other
Combined or individual fast/slow rotation variations create unique multi-beam effects.
■ X-axis: 540°, 16 Bits
■ Y-axis: 270°, 16 Bits
■ Automatic Error Correction:
Both horizontal and vertical movements utilize an optoelectronic reset system; if an accidental collision occurs, it can automatically retrieve and reset the device.
■ Stroboscopic effect: A mechanical stroboscopic design is used, with a stroboscopic frequency of up to 1–1.4 times per second.
The speed can be adjusted arbitrarily.
■ Focus: 0%–100% electronic linear focus adjustment, ultra-smooth adjustment of focal length
■ Nebulization: Uniform soft lighting nebulization effect at 0%～100%
■ Pointing System: A remote bulb control system design that allows intelligent control from a console
The light bulb lights up and turns off, effectively extending its lifespan.
■ Smart fan speed adjustment: The fan automatically reduces speed when the light is off or in strobe off mode
Operate to reduce fan noise and create a favorable performance environment. When the fan encounters an issue
At that time, the display screen will indicate a fan malfunction; the lights will automatically turn off within 60 seconds for protection, effectively preventing...
Bubbling or exploding due to fan malfunctions.
■ Appearance materials: Manufactured by injection molding high-temperature resistant and fire-resistant engineering plastic
■ Protection class: IP20
■ Working environment temperature: -20°C ～40°C
■ Product dimensions: 265 mm high x 323 mm wide x 527 mm deep
■ Base dimensions: 120 mm high × 340 mm wide × 270 mm deep
■ Packaging Weight: 20 Kg
