specifications:
thickness 0.5-300mm
specifications: thickness 0.5-300mm
purpose:
manufacture trucks, built-up buildings, ships, trams, furniture, machines
purpose: manufacture trucks, built-up buildings, ships, trams, furniture, machines
material:
az31b
material: az31b
type:
aluminuium plate
type: aluminuium plate
molding process:
extrusion
molding process: extrusion
surface treatment process:
anodic oxidation
surface treatment process: anodic oxidation
AZ31B magnesium alloy is a common type of magnesium alloy, which has the following characteristics:
1. Chemical composition
Main components: Magnesium (Mg) serves as the base, with elements such as aluminum (Al), zinc (Zn), and manganese (Mn) added.
Typical ingredients: Aluminum (Al): 2.5–3.5%
Zinc (Zn): 0.7–1.3%
Manganese (Mn): 0.15–0.6%
Magnesium (Mg): Residue
2. Mechanical Properties
Strength: Moderate strength, suitable for lightweight structures.
Flexibility: Good plasticity, suitable for hot and cold processing.
Hardness: Moderate, suitable for various applications.
3. Physical Properties
Density: Approximately 1.77–1.80 g/cm³, lightweight material.
Melting point: approximately 605–630°C.
Thermal conductivity: Good, suitable for heat dissipation applications.
Conductivity: Moderate, suitable for electronic devices.
4. Corrosion resistance
Corrosion resistance: It performs well in dry environments, but surface treatment is required in humid or saline conditions.
5. Processing properties
Formability: Easy to stamp, forge, and extrude.
Weldability: Weldable, but attention should be paid to oxidation issues.
6. Application Areas
Aerospace: Used for lightweight components.
Automobile industry: Used for body parts, engine components, etc.
Electronic components: Used for casings, heat sinks, etc.
Sports equipment: Used for lightweight sports gear.
7. Surface Treatment
Common treatments: anodization, electroplating, coating, etc., to enhance corrosion resistance and aesthetics.
8. Precautions
Storage: Must be protected from moisture to prevent corrosion.
Processing: Be aware of high-temperature oxidation; a protective gas is required.
Summary: The AZ318 magnesium alloy plate is widely used in various fields due to its light weight, excellent mechanical properties, and processing capabilities, especially in applications that require lightweight materials.
