Xinnanfang kitchen equipment co. LTD 12yr.
Contacts Zhang Yaqin Chat
Mobile 17757981113
WeChat 939213490
| Custom processing: No | Type: Channel Type | Purpose: For use in large hotels |
| Heating method: Electric heating | Model: R-2E/R-2S | Brand: Weishun |
| Maximum washing height: 450 | Total power: 55 | Maximum washing capacity: 250 |
| Machine type: Dishwasher |
⊙ Stainless steel cleaning pump, durable and powerful in performance, ensuring excellent washing results
⊙ Unique design with concave anti-clogging nozzle, superior cleaning capability
⊙ The cleaning arm and rinsing arm are easy to disassemble and clean without any auxiliary tools
⊙ Dual tank design provides greater washing capacity and superior performance
⊙ Safety protection device; automatically stops when no one picks up the bowl
⊙ Advanced control system; the temperature control switch uses an international brand with CE certification and a US standard circular thermometer display
⊙ The heater is equipped with a limit protection temperature controller to prevent the machine from being damaged due to excessive temperature in the heating package
|
Power requirements |
380V/50Hz/3-phase |
380V/50Hz/3-phase |
380V/50Hz/3-phase |
|
Heating Method |
Electricity |
Electricity |
steam |
|
Water Inlet Temperature (Celsius) |
10—60 |
40—60 |
10—60 |
|
Sink heating power (kilowatts) |
7.5 × 2 |
7.5 × 2 |
－ |
|
Washing and heating power (kilowatts) |
18×2 |
18 |
－ |
|
Total steam consumption (kilograms/hour) |
－ |
－ |
88 |
|
Power of the cleaning pump (kilowatts) |
1.5 × 2 |
1.5 × 2 |
1.5 × 2 |
|
Power of the transmission motor (kilowatts) |
0.2 |
0.2 |
0.2 |
|
Total power (kilowatts) |
55 |
37 |
4 |
|
Total current (amperes) |
84 |
57 |
6 |
|
Power cord cross-section (square millimeters) |
25 |
16 |
2.5 |
|
Air switch rated current (amperes) |
100 |
80 |
16 |
|
Name/Model |
R-2E/R-2S |
|
Heating Method |
Electricity / Steam |
|
Physical dimensions (millimeters) |
1653 × 706 × 1840 |
|
Machine entrance width (mm) |
508 |
|
Maximum washing height (mm) |
450 |
|
Maximum Washing Capacity (Baskets/Hour) |
250 |
|
Maximum water consumption (liters/carton) |
1.2 |
|
Water Tank Capacity (liters) |
90×2 |
|
Heater Volume (Liters) |
2.08 |
|
Washing Temperature (Celsius) |
60~65 |
|
Washing temperature (degrees Celsius) |
82~90 |
|
Pump inlet diameter (inches) |
3/4 |
|
Drain pipe diameter (inches) |
2 |
|
Water inflow pressure (kilograms/cm²) |
2—5 |
|
Water hardness (g/L) |
0.034—0.103 |
⊙ Power installation requires 380V/50Hz/three-phase five-wire, and an independent air switch must be added externally
⊙ During the washing process, additional exhaust hood, dirty dish rack, clean dish rack, shower faucet, cup basket, liquid treatment agent, machine cleaner, and drying agent are required
⊙ The machine can be directly connected to an ordinary water supply system, with a minimum water pressure of 2Kg/cm2
⊙ If an exhaust hood is to be installed, the exhaust volume is —5.7 m³/min at the inlet and —11.3 m³/min at the outlet
.
Company Quality Policy:
Perfection in pursuit—crafting every product with meticulous care.
Scientific management—using advanced modern management methods to control every production step.
Quality first—quality is the lifeblood of an enterprise.
Customer first—providing the best service to every client.
Our advantages:
1. With years of service in kitchens of major star-rated hotels, restaurants, guesthouses, banquets, and staff canteens of enterprises and institutions, as well as student canteens of universities and colleges, we possess extensive experience in kitchen design and kitchen equipment production and installation.
2. Self-produced stoves, cabinets, and smoking equipment feature high quality; the materials meet energy-saving and environmental protection standards. They are completely superior to international products from the US and can also be customized according to non-standard specifications.
3. With over twenty years of experience in the research, development, production, and installation of kitchen equipment, it is one of the kitchen appliance companies with the greatest advantages in energy-saving and environmental protection in Shanghai.
4. A designated OEM supplier for many well-known kitchen appliance brands both domestically and internationally.
Service Purpose:
Driven by customer needs, we create top-tier products. Zero defects are used as the standard for evaluating quality performance, and the cost of non-compliance with standards is used to measure quality. We constantly seek better ways to improve. Our pursuit of product quality is not just about doing well, but about doing the best. We provide you with superior products and services.
Phone: 1775798113 Zhang Yaqin
Q: 9 9 9 2 1 3 4 9 0 WeChat: 9 9 9 2 1 3 4 9 0
