teppanyaki equipment [fan-shaped]-factory direct supply teppanyaki equipment price new south

Shanghai Zhiming Industrial Co., Ltd., 11 years dedicated to high-endGrill equipmentProduction and R&D of, focusing on the production and R&D of grilling equipment.Customized Teppanyaki EquipmentThis is the leading griddle equipment in the nation.Smoke-free grilling equipment,Small Griddle Equipment,Japanese-style Teppanyaki Equipment,French-style Teppanyaki Equipment,Korean-style Teppanyaki EquipmentSupplier,Manufacturerdirect supplyGrilled Skewers PriceandGrill equipment maintenanceZhiming is committed to the research and development of high-end smoke-free environmental protection grilling equipment, with meticulous manufacturing processes and eco-friendly and fashionable product designs, to create Zhiming's international excellence. Senior strength design and research and development team: Zhiming's core advantage is quality, design, and environmental protection, and the large technical elite team and designer team are the powerful guarantee of Zhiming's core advantages. National free hotline: 400-669-8922

The company's production of Zhiming grilling equipment includes seven fixed-shape common devices, portable small grilling devices, and specially customized non-standard grilling devices.
Seven common types of fixed-shape devices: rectangular (seats for 7, 8, or 10), semi-circular (8-seat), arched (10-seat or 12-seat), semicircular (8-seat or 11-seat), horseshoe-shaped (11-seat or 12-seat), oval (10-seat), and circular (12-seat).
Grill equipment with a fan shape

Zhiming Teppanyaki Equipment Function:

Zhiming [Fan-shaped] Smokeless Grilling Equipment is divided intoGas heating typeandElectric heating typeThere are two options. By default, the equipment is gas-heated when it is shipped from the factory. When the sales staff from Zhiming communicate with customers, they will recommend whether the customer should convert to electric heating based on the customer's usage scenario and other factors.
Steel Plate Grilling Equipment Material Description:
1. The frying pan is made of special steel plates with a thickness of 20~28M/M, which are integrated one-piece molded.
2. The foot step is made of 1.0M/M 304# stainless steel plate.
3. The skeleton is made of 4*4*0.25cm tubular materials.
Grilling equipment heating parameters:
1. Electric heating type:
The heater is heated by heating pipes: 380V/7.5KW;
The heater uses a special aluminum plate heating element: 380V/7KW;
The heater uses an electromagnetic stove heating plate: 380V/8KW;
2. Gas-fired dual-ring dual-fire burner:
Gas: 2.92 cubic meters/hour;
Liquefied Petroleum Gas: 0.98 kg/hour;
Natural gas: 1.2 cubic meters per hour;
Attachments: Stainless Steel Exhaust Port, Oil Grid, Oil Hook, 1/9 Plate, Gravity Feet, Swivel Wheels
Gas Grilling Equipment Operation Instructions:
1. First turn on the fan power supply and check the air extraction system. Once it is normal, proceed to the next step.
2. Then turn on the gas burner switch, press the ignition button, and check if the flame is lit in the observation hole.
3. After the fire is lit, turn on the main fire switch to use it normally.
Adjust the size of the gas valve to the appropriate position to control the strength of the burner flame.
Electric Iron Plate Grilling Equipment Operation Instructions:
A. First turn on the fan power supply and check the exhaust system. If everything is normal, proceed to the next step. You can also temporarily turn off the smoke exhaust fan and turn it back on when you actually perform the operation.
B. Then press the power button, and the device will enter the standby state. Press the heating start button to activate the heating system, which will enter the heating state until the temperature reaches the set upper limit, at which point it will stop. Finally, the heating element of the device will cycle between the upper and lower temperature limits under the control of the digital temperature control system.
C. Temperature Control Setup Process: First, turn on the power switch, and the power light will turn on. Then, activate the start button, and press the SET button for 0.5 seconds to display 'CC' on the screen.
For any questions regarding the Zhiming [Fan-shaped] Smokeless Grilling Equipment, please contact Zhiming's National Customer Service Hotline directly: 400-669-8922.

Zhiming [Fan-shaped] Smoke-free Grilling Equipment Packing and Transportation
