Also known as twisted flower mesh, insulation mesh, soft side mesh.

Name: hexagon net

Material: low carbon steel wire, stainless steel wire, PVC wire, copper wire

Knitting: right twist, reverse twist, two-way twist, first braided and then plated, first plated and then braided, hot dip galvanized, electric galvanized, PVC coated plastic.

Features: strong structure, flat surface, good corrosion resistance,antioxidantThe characteristics of

Use: used for raising chicken, duck, goose, rabbit and zoo fence, mechanical equipment protection, highway fence, sports venues fence, road green belt fence. The wire mesh in the production of box-like containers, filled with stone cage, can be used to protect and support seawall, hillside, road, bridge, reservoir and other civil engineering, is the best material for flood control and flood fighting.

Hexagonal network is the metal wire woven Angle network (hexagonal) made of barbed wire, the use of the metal wire diameter is based on the size of the hexagonal and different. If it is a hexagonal wire with galvanized metal coating, use a wire with a diameter of 0.3mm to 2.0mm. If it is a hexagonal mesh with a PVC covered wire, use a PVC(metal) wire with an outer diameter of 0.8mm to 2.6mm. Twisted into a hexagonal shape, the outer edge of the frame can be made into a single side, two sides, can move the edge silk.

The English name hexagonal wire netting

Hexagonal wire mesh

Front twist, back twist (back twist).

(1) easy to use, it can only be used by tiling the wall surface and building cement;

(2) simple construction, no need for special technology;

(3) have a strong ability to resist natural damage and corrosion resistance and the impact of adverse climate;

(4) can withstand a wide range of deformation, but still do not collapse. Fixed thermal insulation effect;

(5) excellent process basis to ensure the uniformity of coating thickness, corrosion resistance is stronger;

(6) save transportation costs. Can be shrunk into small rolls, and involved in moisture-proof paper packaging, take up little space.

(7) the heavy hexagonal mesh is made of high quality low carbon steel wire galvanized large wire woven, the tensile strength of steel wire is not less than 38kg/m2, steel wire diameter up to 2.0mm-3.2mm, steel wire surface usually also use hot dip galvanized protection, the thickness of galvanized protective layer can be made according to customer requirements, the maximum amount of galvanized up to 300g/m2.

(8) galvanized wire plastic hexagonal mesh is galvanized iron wire on the surface of a layer of PVC protective layer, and then woven into a variety of specifications of the hexagonal mesh. This layer of PVC protection will greatly increase the service life of the network, and through the choice of different colors, so that it can be integrated with the surrounding natural environment.

Hexagonal net weight calculation method: silk.× silk.× cardinality x length x width ÷2=kg cardinality: 1/2\"=2.15     1 \"= 1.27 3/4 \"= 1.6          \"5/8 = 1.87                   5/4 \"= 1.091 x1/2:

3\"=0.4 silk warp.× silk warp.×2x length x width ÷8x3=kg

Low carbon steel wire, stainless steel wire

Positive twist, reverse twist, two-way twist, first after plating, first after plating, and hot dip galvanized, galvanized, PVC coated plastic

The structure is firm, the surface is flat, has the good anti - corrosion, anti - oxidation and so on characteristic

Width: 0.5 m, 2 m

Hole length: 1.5cm*1.2inch 2cm*3/4inch 1.8cm*5/8inch 2.5cm*1 inch 3cm*1.25inch 4cm*1.5inch 5cm*2inch

Heavy hexagonal mesh, also known as large specification hexagonal mesh, or gabion mesh, made of high quality steel wire twisted mesh machine. Can be used for slope support,Foundation pit supporting, mountain rock face hanging net spraying, slope planting (greening), railway highway isolation blocking, it can also be made of stone cage, stone pad, used for rivers, DAMS and seawall scour protection and reservoir, river closure with stone cage.

(1) galvanized large wire hexagonal mesh is made of high-quality low carbon steel wire, the tensile strength of steel wire is not less than 35kg/m2, steel wire diameter up to 2.0mm-4.0mm, steel wire surface usually also use hot dip galvanized protection, galvanized protective layer thickness can be made according to customer requirements, the general amount of galvanized up to 200g/m2.

(2) galvanized wire plastic hexagonal mesh is galvanized iron wire on the surface of a layer of PVC protective layer, and then woven into a variety of specifications of the hexagonal mesh. This layer of PVC protection will greatly increase the service life of the network, and through the choice of different colors, so that it can be integrated with the surrounding natural environment.

Of the goods Mesh (SWG) The wire number (SWG) Wire diameter (mm) Width X length Weight (kg/ roll) Coil diameter (mm) note

Twisting hexagonal net 1/2 22 0.71 3 'x100' 15.00 150 Net width can be produced within 2 meters, and there are two single bilateral.

Twisting hexagonal net 1/2 23 0.62 3 'x100' 11.50 150

Twisting hexagonal net 1/2 24 0.56 3 'x100' 09.30 140

Twisting hexagonal net 1/2 25 0.51 3 'x100' 07.50 130

Twisting hexagonal net 5/8 22 0.71 3 'x100' 13.00 150 Net width can be produced within 1.2 meters, and there are two single bilateral.

Twisting hexagonal net 5/8 23 0.62 3 'x100' 10.00 140

Twisting hexagonal net 5/8 24 0.56 3 'x100' 08.10 130

Twisting hexagonal net 5/8 25 0.51 3 'x100' 06.70 120

Twisting hexagonal net Three quarters of 21 0.81 3 'x100' 14.80 170 Net width can be produced within 2 meters, and there are two single bilateral.

Twisting hexagonal net Three quarters of 22 0.71 3 'x100' 11.00 160

Twisting hexagonal net Three quarters of 23 0.62 3 'x100' 08.70 150

Twisting hexagonal net Three quarters of 24 0.56 3 'x100' 07.10 140

Front and back twist hexagonal net 1 20 0.91 3 'x100' 14.50 160 Right twist network can produce within 1.2 meters; The anti-twist mesh can be produced within 2 meters, and there are two kinds of single and bilateral reinforcing bars.

Front and back twist hexagonal net 1 21 0.81 3 'x100' 11.50 150

Front and back twist hexagonal net 1 22 0.71 3 'x100' 09.00 140

Front and back twist hexagonal net 1 23 0.62 3 'x100' 06.80 130

Front and back twist hexagonal net 1 24 0.56 3 'x100' 05.60 150

Front and back twist hexagonal net 6/5 19 1.01 3 'x100' 15.00 170

Front and back twist hexagonal net 6/5 20 0.91 3 'x100' 12.50 160

Front and back twist hexagonal net 6/5 20 0.91 3 'x100' 12.50 160

Front and back twist hexagonal net 6/5 21 0.81 3 'x100' 09.90 150

Front and back twist hexagonal net 6/5 22 0.71 3 'x100 07.60 150

Reverse twist hexagonal net 3/2 18 1.20 3 'x100' 17.00 200 Net width can be produced within 2 meters, and there are two kinds of single and double side band stiffeners.

Reverse twist hexagonal net 3/2 19 1.01 3 'x100' 12.00 170

Reverse twist hexagonal net 3/2 20 0.91 3 'x100' 09.70 160

Reverse twist hexagonal net 3/2 21 0.81 3 'x100' 07.70 145

Reverse twist hexagonal net 3/2 22 0.71 3 'x100' 06.00 140

Reverse twist hexagonal net 2 18 1.20 3 'x100' 12.00 180

Reverse twist hexagonal net 2 19 1.01 3 'x100' 08.50 170

Reverse twist hexagonal net 2 20 0.91 3 'x100' 07.00 150

Reverse twist hexagonal net 2 21 0.81 3 'x100' 05.50 145

Reverse twist hexagonal net 2 22 0.71 3 'x100' 04.30 140

Twisting hexagonal net 3 18 1.20 3 'x100' 08.80 170 Wide can be produced within 2 meters, and single bilateral two kinds.

Twisting hexagonal net 3 19 1.01 3 'x100' 06.00 170

Twisting hexagonal net 3 20 0.91 3 'x100' 05.00 160
