  • Updated: 2020-09-23 16:46
  • About Product:The ice machine does not require water resources and the operating cost is low. Easy to install and use, no need for other supporting equipment, as long as power supply can be put into use, suitable for areas with severe water shortage or rare water supply. For details, please contact: 0579-89355500 Contact Information: 139 5793 7914
EXW Price:
Above 1pcs   CN ¥ 4,500 /pc
Send Inquiry
Contact
Main
Products:
.
Contacts: siriChat
Mobile: 86-18058971627
E-mail: 1693667428@qq.com
WeChat: dreamcare18
Address: 21032 , 2 F, Yiwu Production Material Market.

Weight: 180.0 kg/ piecePacking quantity: 1 / carton

FCL weight: 190kg/cartonFCL: 1.131 cubic meters/box


Better quality, better service!!

detailsPlease consult: Landline:0579-89355500.

                     Mobile phone: 139 5793 7914 (same number as WeChat)


Product display

productintroduce

Product Features:

The chilled water pump in a storage tank flows in a continuous cycle through a plate-type or grid evaporator;

After operation of the compressor, it is sucked into the evaporator at a low temperature of -10 to -18 degrees. Frozen water freezes on the surface of the cooler evaporator at 0 degrees. When the ice freezes to a certain thickness, the refrigerantEvaporation temperatureAfter reaching the set temperature of temperature control, namely through defrosting solenoid valve often USES heat pump form deicing, and then realize the next cycle.

Yiwu Junda refrigeration Equipment Co., Ltd. is a professional manufacturer of fresh-keeping worktable, a well-known enterprise in the refrigeration industry in China, a supplier of high-quality refrigeration equipment, specializing in the production and sales of the fourthDoor freezer, six door freezer, fresh-keeping working table, fresh-keeping display cabinet and other refrigeration products. Welcome new and old customers to dial the free hotline consultation. 79Better quality, better service, please consult +86 98355500 for details

Scope of Application

Hotel, guesthouse, canteen, supermarket, convenience store fresh food, fruit, milk


Products use

1. Take down the outer packing and take out the attached file bag, inlet pipe, drain pipe, ice scoop, gasket and other accessories from the ice storage box.
2. Place the ice maker in a ventilation place with a space no less than 150mm from the wall, away from the heat source, and ensure the smooth placement of the machine.
3. Connect a 12 soft plastic corrugated drain pipe attached at random with outlet pipe 7 on the back of the machine, and place the other end in the water box (self-matching) or the sewer opening.
4. Connect one end of the randomly attached water inlet pipe to the tap with a 3/4\" threaded joint of the drinkable water supply pipe, the water supply pipe has a water pressure of 1.5-3kg /cm2, and the other end is connected to the threaded joint of the water valve on the back of the ice maker. Note that sealing gasket should be placed on both ends of the water inlet pipe when connecting (randomly arranged).
5. Turn on the tap to ensure smooth flow of water in the inlet pipe.
6. Plug in the power plug and press the warping switch on the operation panel, then the ice maker will start to work. The ice maker will make ice, remove ice and store ice automatically and continuously from water filling. When the external water supply pipe (or pure water supply system) is cut off or water supply fault occurs, the light of water shortage on the operating panel of the ice maker will light up and the ice maker will stop automatically.

After-sales service

爱我就Q我吧

Shopping need to know
1. During handling, the inclined Angle of the box body shall not be greater than 45 degrees, and inversion is prohibited, so as to avoid the failure of the compressor or refrigeration system.
2. If the ice making machine is used again after the first use or long-term shutdown, unscrew the drain nut 5 and put the container in the water-holding position. The first two ice-making processes are the cleaning process of the pipeline system of the ice making machine, so the ice cubes are unfit to eat.
3. The ice maker shall not be used in the open air, shall not be directly watered, and shall not be placed in a wet or easily wet place. It should be placed on a well-ventilated plane away from heat source, surrounded by non-corrosive gas, with a space of at least 150mm around it to ensure the free flow of air.
4. After the ice maker is in place, it should be turned on 12 hours after the first use.
5. Do not place items or water containers on the ice maker.
6. Do not touch live parts such as power plugs with wet hands.
7. Never turn on the ice maker to make repairs unless you are a professional repairman.
8. Unauthorized modification of machines is absolutely prohibited.
9. Power range :187V to 242V/50Hz
10. Rated capacity of conductor shall be & GT; =6A, cross-section area of conductor 0.75mm2, for IM-80, rated capacity of conductor should be & GT; =10A, traverse area is 1.Omm2, traverse can be single or multiple. A fuse rated at 5A is required (10A fuse for IM-80).
11. Do not damage the power cord. If the power cord is processed, pulled, bound, or if heavy objects are placed on the power cord, once the outer cover is damaged, the power cord may be damaged, leading to electric shock or fire.
12. Operating temperature range: Environment :10℃ to 35℃, water temperature :10℃ to 30℃.
13. A separate three-hole socket must be used and have a good grounding wire.
