Lifting BeltIntroduction

Hanging belt introduction: Hanging belts can be classified by type into flat hanging belts, flexible hanging belts, and loop hanging belts. Flat hanging belts can be divided into single-layer flat hanging belts, double-layer flat hanging belts, and multi-layer hanging belts.is adopted100% PES is woven and then sewn together; and the ends of the hoisting belt can be reinforced with rings or metal accessories to increase strength; flat belts are woven by a loom in one step and processed with different sewing methods; the standard tonnage of flat belts can be distinguished by color, and also by the width to distinguish different tonnage capacities.Flexible hoisting straps can be classified by type into:Type A and B flexible straps, commonly known as: round sets; are made by filling a circular sheath with a bearing core after being sewn together. Standard tonnage is indicated by color.

Basic parameters: The maximum load range of flat hoisting straps and flexible straps is 1-30 tons, with safety factors of 4.5/5/6/7 times; Tonnage is indicated by 1T-purple, 2T-green, 3T-yellow, 4T-grey, 5T-red, 6T-brown, 8T-blue, 10T-orange, 12T-orange, 20T-orange, 30T-orange;Length range: 1-100 meters; Temperature range: -40℃ to 100℃.

Usage Notes: When performing hoisting operations, this flat hoisting strap can provide a wide, smooth bearing surface, making it particularly suitable for hoisting objects with soft surfaces. Since there is no contact with metal parts, it causes minimal damage to the painted surfaces of the hoisted objects. Flat hoisting straps offer higher protection against wear and damage. In general hoisting applications, the superiority of the hoisting strap allows it to have a relatively long service life. However, it is also necessary to use the correct protection sleeve during hoisting operations to prevent the hoisting strap from being cut by sharp objects or the hoisted object.

Lifting Beltadvantages

1. It can be single-layer, double-layer, or multi-layer, and the sewing methods are diverse.

2. The size can be determined according to customer requirements.

3. The bearing surface is wide, which can reduce the pressure of surface load.

4. When hoisting smooth and delicate objects on the exterior surface, it will not damage the hoisted object.

5. There are various methods of hoisting.

6. High strength-to-weight ratio.

7. Additional anti-wear protection sleeve and anti-cut-off protection sleeve can be added.

8. Features unique labels, using international standard colors to distinguish the carrying tonnage, and it is easy to identify even when the sling is worn.

9. Lightweight and soft, easy to use even in small spaces.

10、surface can be processedPU hardening treatment, enhancing wear resistance.

11、Non-conductive, no risk of electric shock.

12、Complies with European standardsEN1492-1：2000 and China's national standard JB/T8521-1997.

ThirteenElastic Strain of Lifting Belt≤7%。

14、Temperature Range of Use-40℃ to 100℃

Maintenance Method

1When moving the hoisting belt and the cargo, do not drag it. Do not allow it to become knotted.

2Do not connect the soft ring with any device that may cause damage or wear.

3When carrying, do not twist it.

4Should not use a sling without a cover to carry goods with sharp corners or edges.

5Avoid the soft ring opening angle exceeding 20 degrees.°。

6The straps should be stored in conditions that avoid light and UV radiation.

7The hoisting belt should not be stored next to open flames or other heat sources.

8When not using the hoisting strap, it should be placed in a place with good lighting.
