multifunctional cutter-rower hand-held corn straw forage harvester agricultural mobile harvesting and drying machine

Ruichang Gold Generating equipment (Wuxi) Co., Ltd. 13yr.

Contacts Mao Keqiang Chat

Mobile 86-18857971111

E-mail 18857971111@qq.com

Click to Contact Yiwugo official customer service for International sourcing.

Yiwugo official customer service X

Whatsapp:

Email： yiwubuy@yiwugo.com

Description

brand: deou

applicable object: straw

product features: cutter-rower

whether cross-border export is exclusively available: no

total weight of the whole machine: 120-135kg

product type: cutter-rower

degree of automation: semi-automatic

product size: 2300*900*1360

applicable scenarios: agricultural

power: 1.25

A gentle reminder: The prices and parameter images on the website are for reference only. For machine parameters and detailed specifications, please contact us for confirmation.

Ordering via online bidding is even more affordable!!!


Type 120 harvester consists of two main parts: the supporting main unit and the harvester machine itself. The supporting main unit comprises an engine, a transmission gearbox, a frame, a multifunctional handle for control mechanisms, and wider tires. Currently, the supporting main unit mainly consists of components such as the transmission gearbox, harvester machine frame, and spade wheel.Primarily used for harvesting crops such as wheat and rice, this system is suitable for platform terrain conditions and plant heights0.5~1.5


Primary Technical Parameters
Supporting host		Type 120 Drying Machine
Host parameters	Main separation mode	Gear coupling type
	Pedal Clutch	Right hand manual clutch
	Diameter of the walking wheel	470 million
	Number of Gear Shifts for Driving	Forward gear, Reverse gear, Neutral gear
	Speed of the power output shaft	1800 revolutions per minute
Cutting and drying machine parameters	Physical dimensions in millimeters (length × width × height)		TNS-4S-120
			2,390 x 1,470 x 900
	Weight (slicing machine)		125 KG
	Job assignment width		1.2 million
	Tabletop form	Vertical
	Auxiliary placement format	Place the lateral strip
	Cutting tool stroke	50 million
	Diameter of the Piaohe Star Wheel	280MM
	Work Speed	5 kilometers per hour
	Stubble height	50~120MM
	Laying Angle	90° ± 20°
	Total Loss Rate	≤1%


e7e5efeb31b785806c8ebdecf2cfa8

93b575d9e5a479c62f81142aa8f57c

a9682f756a04e311544f94f19e67a5

德欧公司简介1

德欧简介

f69a900d911acf30c2b992f5b04372

Please note the model number for online ordering. Before shipping, we conduct multiple inspections by quality control staff at each stage to ensure everything is correct before delivery. Since the machine is quite large, minor scratches or paint peeling that occur during transportation are not covered under warranty returns or exchanges. If there are no quality issues, they are also not eligible for returns or exchanges. Thank you for your cooperation.
