gx-662 horizontal self-adhesive sticker labeling machine, automatic round bottle labeling machine, production capacity 250 bottles per minute.

Guangxin packing machinery co. LTD 8yr.

Contacts Wu Fangfei Chat

Mobile 13750955966

E-mail 541618760@qq.com

Click to Contact Yiwugo official customer service for International sourcing.

Yiwugo official customer service X

Whatsapp:

Email： yiwubuy@yiwugo.com

Description

brand: guangxin machinery

model: gx-662

power: 1.5kw

voltage: ac220v 50/60hz

production capacity: 0~250 bottles/minute

labeling accuracy: ± 1mm

weight of the whole machine: 230kg

origin: china

GX-662 Horizontal (round bottle) self-adhesive labeling machine, driven by stepper motors, equipped with PLC control system and touchscreen interface. It automatically performs the entire process of bottle loading, bottle separation, label delivery, labeling, rolling, and material discharge. Suitable for labeling round containers in industries such as pharmaceuticals, chemical manufacturing, and food processing. The labeling process is automated, easy to operate, with high production speed, consistent labeling positions, and a neat appearance.

Technical Parameters

Model Number	GX-662
Product Name	Horizontal self-adhesive labeling machine
Voltage specifications	AC2 20V；50/60Hz
Power	1.5KW
Production capacity	0~250 bottles/minute
Labeling Accuracy	±1mm
Print batch number	A coding machine with motor drive or cylinder drive can be selected.
Scope of Applicable Products	Outer diameter: Φ8~Φ50; Height: 30~200
Applicable Tag Range	Height: 15~100; Length: 20~300
Maximum tag supply	Diameter: 300 mm; Inner diameter of the reel: 76 mm
Total weight of the machine	230 KG
Working Method	Left in, right out / Right in, left out (can be specified as needed)
Main Configuration	Stepper motor drive; Delta or Panasonic PLC control system; Kunlun Tongtai touchscreen HMI; KEYENCE optical fiber components from Japan
Body material	High-quality T6 aluminum alloy + SUS304 stainless steel, compliant with GMP standards
Quality Assurance	Mechanical parts: 1 year / Electrical components: 6 months

The above parameters shall be subject to the random User Manual.

Guangxin Machinery｜GX-662 Horizontal Self-Adhesive Labeling Machine. This product is offered by a yiwugo.com certified merchant. For quotes and delivery schedules, please leave a message under “Discuss Now” on the page.
