product Information:
Product Size: 590*370*240
Packing size: 630*4500*260
Product voltage: 220V
Product Power: 1.5KW
Product gross weight: 11KG
Product Volume: 0.07CBM
Product Display
Product Use
the whole is made of high-quality all stainless steel, and the within the cabinet adopts high-quality and high-efficiency heating components produced by imported equipment, which are directly heated by soaking in water, with high thermal efficiency. The Cabinet is equipped with an automatic water inlet device, when the water level reaches a certain height, the equipment works normally, and the cabinet is also equipped with thermostat. When using, the temperature can be adjusted according to needs to achieve the purpose of keeping various soup and dishes warm.
The customer shopping you need to know
Installation Instructions
1, the cabinet is placed in the environment of 5℃ ~ 40℃, and the relative humidity ≤ 90% is appropriate.
2. There is no conductive dust around, explosive gas and aggressive gas environment that can seriously damage metal and insulation.
3. Check whether the components are intact, the water level float valve is adjusted to the normal water level, and the drain valve is closed.
4. Equipped with special electric power switch to ensure effective and reliable grounding.
5. This equipment shall not be used outdoors.
Operating Procedures(1) waterway installation
1. Place the hot soup pool cabinet horizontally in the application place and connect the inlet tube inlet tube the machine.
2. Applicable water pressure is 0.10 ~ 0.3Mpa
(Ii) electrical installation
1, check the line is loose, according to the product model will connect wire in the corresponding power supply.
2. This cabinet belongs to class I electrical equipment and is equipped with special socket to ensure reliable grounding.
(3) commissioning and normal use
1. Confirm that the drain valve is closed before opening the inlet valve.
2. After the water level reaches the designated height, it can be heated by power-on.
3. When the water is heated to the required temperature (controlled by the thermostat), put the required insulation soup or dish in the basin to keep it warm.
The matters needing attention and maintenance
1. Before each use, check whether the water level of the water tank is on the normal water level line. If there is no water or the water level is too low, do not turn on the power switch to prevent burning (electric heating element)
2. In case of temporary water failure or other reasons, the water level drops and the floating ball falls, the power switch should be turned off in time, and the reason should be found out before the water level is restored to the normal water level.
3. When cleaning the water tank, do not use a strong metal shovel to scratch the surface of the electric heating element.
4. Scrub the electric heating element regularly (generally once a week).
5. If you don't need to remove the power cord for a long time, put the residual water in the box and scrub it clean.
6. The down time is too long. When it is used again, please ask the professional to repair it before it can be used.
